ANTEC VP 600W PLUS NON-MODULAR PSU

Description

The Antec VP 600W Plus Non-Modular PSU is discreet and durable with an 80 PLUS® 230V standard certification and a 120mm silent fan. It provides 600w of continuous output power with a reduced power draw of up to 85% efficiency. This PSU has two-PCI-E connectors for dual GPU installations. Antec’s Thermal Manager optimises the fan for optimal heat and noise control.
n

Specifications:

n

• n
  • Modularity: Non-Modular

n

• • Dimensions: 15 x 14 x 8.6 cm

n

• • Output Capacity: 600W

n

• • Input Voltage: 200-240 VAC ±10%

n

• • Input Current: 5A

n

• • Input Frequency Range: 47Hz-63Hz

n

• • PFC: Active PFC (>0.9 typical)

n

• • Power Good Signal: 100-500ms

n

• • Efficiency: 85% Typically

n

• • Protection: UVP/OVP/SCP/OPP/NLO

n

• • Regulatory: TUV/CB/CE/KC

n

• • Fan: 120mm Silent Fan

n

• • Certifications: 80 Plus

n

• • Connectors:
    n
    • n
      • 1x MB 24(20+4) Pin

    n

    • • 1x 8(4+4) Pin EPS 12V

    n

    • • 2x 8(6+2) Pin PCI-E

    n

    • • 7x SATA

    n

    • • 2x Molex

    n

    • • 1x FDD

    n

    n

n

n

What’s In The Box:

n

• n
  • Antec VP 600W PSU x1

n

• • Power cable x1

n

• • Pack of screws x1
