ASUS AMD Ryzen X570 ROG Crosshair VIII IMPACT WiFi AM4 PCIe 4.0 Mini-DTX Motherboard

Compact Design

Impact’s unusual Mini-DTX form factor is a deliberate choice. Many Mini-ITX cases ship with enough space for a dual-slot graphics card, meaning there’s typically unused space below the bottom PCIe slot – space that could be utilized to mount more components or enable additional features. Being marginally taller than mini-ITX allows Impact to exploit this unused space, allowing ROG engineers to squeeze in features while still fitting a large proportion of mini-ITX PC cases.

ROG Crosshair VIII Impact stacks up storage, audio and control features onto innovative vertical daughter boards, leaving us spare room onboard to add more connectivity and engineer features normally found on ATX boards into a small-form-factor (SFF) footprint.

The Impact

Heatsinks
We’ve fully exploited the extra space afforded by Impact’s Mini-DTX form factor to dedicate more space to the board’s VRM and chipset cooling design.

Optimal Performance

ROG Crosshair VIII Impact is equipped with an optimized power design and comprehensive cooling to exploit prodigious might of the latest AMD Ryzen processors without performance-zapping thermal throttling. It also packs innovations to double up on memory and push frequencies to the max.

Power Design
The monstrous compute power of multi-core processors necessitates a power circuit that rapidly responds to massive current swings. Featuring an array of 10 strategically paired power stages, the Impact’s VRM is geared for any workload and all operating conditions.

8-pin ProCool II Power Connectors
The latest ProCool II power connector offers higher endurance and longer lifespan by lowering impedance to prevent hotspots and connector failure. The new design includes upgrades to metal amour and solid pins for better dissipation.

Memory – OptiMem III DDR4 4800+ MHz (OC)
Infused with proprietary memory trace layout tweaks that improve signal integrity and mitigate noise, Optimem III allows memory kits to run at lower latencies, reduced voltages, and operate at higher frequencies. Stack the Impact with your favorite modules and maximize Ryzen 3000 throughput for applications that demand massive bandwidth, or balance infinity fabric and memory performance for a diverse range of workloads.

Cooler by Design
ROG Crosshair VIII Impact features the most comprehensive cooling options ever, configurable via Fan Xpert 4 or the UEFI BIOS. Each header can be set to monitor and react to three user-configurable thermal sensors for workload-based cooling. And all settings can be easily managed by Fan Xpert 4 or UEFI.

Optimization

ROG gives you powerful tools that make optimizing your system fast and easy. For those who relish fine-grained control, the UEFI BIOS has a wealth of advanced options organized into intuitive categories that provide the ability to tweak every aspect of your system.

UEFI BIOS
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as comprehensive features for seasoned veterans.

Designed to simplify setup, EZ mode presents all the vital settings and stats on a single page. With guided wizards, drag-and-drop functionality, and one-click application of important settings, your rig will be up and running in no time.

Accurate Voltage Monitoring
Conventional motherboards use single-ended sensing tapped from a location that isn’t ideal, leading to a large disparity between the actual voltage fed to the CPU and the value reported to software. The Impact features a differential sensing circuit that simplifies overclocking and tuning by allowing you to track voltages more accurately.

5-way Optimization – Performance Level Up
RAI Suite 3’s dashboard-style control panel lets you fine-tune almost every aspect of your system. Get the best balance between performance, cooling, stability, and efficiency via one simple and intuitive interface.

• • TPU: CPU-performance Boost
    The TurboV Processing Unit (TPU) is an intelligent onboard micro-controller that provides an array of system-tuning features, including the ability to fine-tune voltages, monitor system stats and adjust overclocking parameters.

• • EPU: All-around Energy Efficiency
    With the Energy Processing Unit (EPU) you’ll enjoy system-wide power savings. The EPU automatically optimizes power consumption and maximizes savings with Away mode – a smart setting that creates an extreme energy-saving scenario by shutting down unused I/O controllers.

• • Fan Xpert 4: Flexible Cooling Controls for Air or Liquid
    Enjoy comprehensive control over fans, water pumps and all-in-one (AIO) coolers, via either Fan Expert 4 or our award-winning UEFI. Whether you’re cooling with air or water, Auto-Tuning mode intelligently configures all parameters with a single click. There’s also an Extreme Quiet mode, which reduces all fan speeds to below the default minimum – keeping your system whisper-quiet when performing light tasks.

• • Digital+ Power Controls: Precise Digital Power Control
    The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, switching frequency and power-efficiency settings, allowing you to fine-tune CPU voltage regulation for ultimate stability and performance.

• • Turbo App
    AMD’s processors feature per-core tuning, and the ASUS Turbo app makes use of this feature by letting you assign applications to specific processor cores, prioritizing computing power where it’s needed most.

Connectivity

ROG Crosshair VIII Impact offers advanced connectivity to ensure seamless gaming experiences. This includes Intel Ethernet and the latest Wi-Fi 6 (802.11ax). It also has the two M.2 slots integrated into the SO-DIMM module, plus the same SupremeFX audio codec you’ll find on ATX ROG boards.
Networking: Wi-Fi 6 (AX200)
ROG Crosshair VIII Impact comes with onboard Wi-Fi 6 (802.11ax) support, offering ultrafast networking speeds, improved network capacity and better performance in dense Wi-Fi environments for exceptional online gaming experiences with the convenience of a wireless connection.

Intel® Ethernet
ROG Crosshair VIII Impact features the latest Intel® Ethernet (I211-AT) ensuring data exchanges with your network and the outside world are fast and smooth. Intel LAN reduces CPU overhead and increases TCP and UDP throughput, keeping more processing power.

Audio: SupremeFX
ROG Crosshair VIII Impact’s SupremeFX audio features a dedicated card to limit signal interference, and packs the SupremeFX S1220 codec, ESS® ES9023P DAC and premium capacitors for enthusiast-grade audio performance.

Storage: Dual PCIe 4.0 M.2
Dual PCIe 4.0 M.2 slots support up to 2280 and provide NVMe SSD RAID support for an incredible performance boost. Create a RAID configuration with two PCIe 4.0 storage devices to enjoy the fastest data-transfer speeds on the 3rd Generation AMD Ryzen platform.

ROG SO-DIMM.2
ROG SO-DIMM.2 is an innovative expansion card that allows two PCIe 4.0 M.2 drives to be connected via Impact’s SO-DIMM interface. You can then add metal heatsinks, helping to control thermals for maximum performance while elevating the aesthetics.

ASUS Node
ASUS Node is a proprietary bi-directional interface that allow ASUS motherboards to communicate with other system components, opening up a wealth of new options for system builders.

Personalization

ROG provides a range of intuitive software that enables easy control of your advanced gaming hardware and ensures seamless component compatibility. From RGB lighting, networking and audio to storage optimization and more, ROG gives you the power to personalize your system just the way you want.

GameFirst V Network Control
GameFirst V is an ROG-exclusive tool that optimizes network traffic and your connection for faster, lag-free online gaming. Select the best Wi-Fi channel for maximum stability and minimum interference, team your gateways and keep tabs on bandwidth-hogging apps, all from an intuitive interface that enables easy, on-the-fly adjustments.

Sonic Studio III
Sonic Studio supports HRTF-based (head-related transfer function*) virtual surround for VR headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options and one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset.
* A head-related transfer function is an audio algorithm derived from sound data recorded through a dummy head. Test tones are played from a spherical grid around the dummy head to obtain subtle changes in sounds that come from different directions. The results are combined into an algorithm that allows Sonic Studio’s virtual surround to process sound true to life.

Armoury Crate
Armoury Crate is a new software utility designed to give you centralized control of supported ROG gaming products. From a single intuitive interface, Armoury Crate lets you easily customize RGB lighting and effects for every compatible device in your arsenal and synchronize them with Aura Sync for unified system lighting effects. The software also provides control of settings for a select and growing number of ROG products, including keyboard and mouse preferences as well as laptop overclocking and fan speeds, making it easier to tune the look and feel of your system. Armoury Crate even features dedicated product registration and ROG news areas to help you stay in touch with the ROG gaming community.

RAMCache III
RAMCache turns milliseconds into microseconds to boost game-load times. Fully compatible with the latest NVM Express storage options, its uniquely intelligent technology effectively caches an entire storage device so that favorite games and apps launch at breakneck speeds.

The Power of AMD

AMD X570 Chipset
The AMD® X570 chipset delivers outstanding overclocking capabilities for the latest AMD® AM4 socket for 3rd and 2nd Gen AMD® Ryzen™ /2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors. It is optimized for multiple GPU configurations, including NVIDIA SLI® and AMD® CrossFireX™. It also supports x16 PCI Express 4.0/3.0 lanes and provides 10Gb/s USB 3.2 Gen 2 ports and 6 Gb/s SATA ports for faster data retrieval.

AMD AM4 Socket for 3rd and 2nd Gen AMD Ryzen™ / 2nd and 1st Gen AMD® Ryzen™ with Radeon™ Vega Graphics Processors
The high-performance 3rd Gen AMD® Ryzen™ processors are based on the next-gen 7nm Zen architecture and support up to 16 processor cores. AMD® AM4-socket processors feature dual-channel DDR4 memory, native 10Gb/s USB 3.2 Gen 2 and x16 PCI Express 4.0/3.0 lanes for superb performance.

Additional Information:

Visit the Manufacturer Web Page for Full Details

• • Supports AMD® AM4 Socket for 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors

• • Windows® 10 (64-bit)
