Description
Part numberB5602CBA-OI716512B0X
Part number90NX05H1-M007E0
SPECIFICATIONS |
|
| Brand | ASUS |
| Series | ExpertBook B5 B5602 |
| Model | B5602CBA-OI716512B0X(90NX05H1-M007E0) |
| Processor | |
| Model | Core i7-1260P |
| Chipset Manufacturer | Intel |
| Max Turbo Frequency | 4.70GHz |
| Performance-core Max Turbo Frequency | 4.70GHz |
| Efficient-core Max Turbo Frequency | 3.40GHz |
| Performance-cores | 4 |
| Efficient-cores | 8 |
| Thread Count | 16 |
| Cache | 18 MB Intel Smart Cache |
| Lithography | Intel 7 |
| Memory | |
| Total Installed | 16GB(8GB Onboard + 8GB SO-DIMM) |
| Type | DDR5 |
| Maximum Capacity | Max Up to 40GB |
| 1x SO-DIMM Slot (Occupied) | |
| Graphics | |
| Type | Dedicated |
| Model | Intel Iris Xe Graphics |
| Display | |
| Size | 16″ |
| Panel Type | OLED |
| VESA Display HDR Certification | VESA Display HDR True Black 600 |
| Brightness | 400nits |
| Color gamut | DCI-P3: 100% |
| Pantone | Pantone Validated |
| Response Time Max | 1ms |
| Glare | Glossy Display |
| Native Resolution | WQUXGA (3840×2400) 16:10 |
| Storage | |
| Installed | 1x 512GB M.2 NVMe PCIe 4.0 SSD |
| Supported | 2x M.2 2280 PCIe 4.0×4 (1x Occupied) |
| Input / Output | |
| Ports | 1x USB 2.0 Type-A |
| 1x USB 3.2 Gen 2 Type-A | |
| 2x Thunderbolt 4 Supports Display / Power Delivery | |
| 1x HDMI 2.0b | |
| 1x 3.5mm Combo Audio Jack | |
| 1x RJ45 Gigabit Ethernet | |
| Micro SD card reader | |
| Audio | Dolby Atmos |
| Built-in speaker | |
| Built-in array microphone | |
| Communications | |
| Ethernet | Gigabit Ethernet |
| Wi-Fi | 802.11ax 2×2 Dual-Band WiFi 6 |
| Bluetooth | Bluetooth v5.2 |
| Integrated Input Devices | |
| Keyboard | Backlit Chiclet Keyboard with Num-key |
| Pointing Device | Touchpad |
| FingerPrint | FingerPrint |
| General | |
| Webcam | 720p HD camera with IR function to support Windows Hello With privacy shutter |
| Operating System | Windows 11 Pro |
| Battery | 50WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter | TYPE-C, 90W AC Adapter |
| Output: 20V DC, 4.5A, 90W | |
| Input: 100~240V AC 50/60Hz universal | |
| Dimensions | 358.2mm x 261.2mm x 19.9mm |
| Weight | 1.40Kg |
| Warranty Information | |
| Warranty | 1 Year Warranty |
