Description
SPECIFICATIONS |
|
| Brand | ASUS |
| Series | TUF Gaming F15 |
| Model | FX506LHB-I58512B0W(90NR03U2-M00AB0) |
| Processor | |
| Model | Core i5-10300H |
| Chipset Manufacturer | Intel |
| Base Clock | 2.50GHz |
| Boost Clock | 4.50GHz |
| Core Count | 4 |
| Thread Count | 8 |
| Cache | 8MB Intel Smart Cache |
| Lithography | 14 nm |
| Memory | |
| Total Installed | 8GB |
| Type | DDR4 |
| Speed | 2933MHz |
| Maximum Capacity | 2x SO-DIMM Slots(1x Occupied) |
| Max 32GB | |
| Graphics | |
| Type | Dedicated |
| Model | NVIDIA GeForce GTX 1650 |
| GPU Architecture | NVIDIA Turing TU117 |
| Execution Units | 1024 CUDA Cores |
| Boost Clock | 1515MHz |
| Memory | 4GB GDDR6 |
| Memory Bandwidth | 192GBps |
| Features | NVIDIA GeForce Experience |
| NVIDIA ShadowPlay | |
| NVIDIA Physx | |
| NVIDIA Image Scaling | |
| NVIDIA Ansel | |
| NVIDIA NVENC Encode and Decode | |
| NVIDIA Studio Drivers | |
| GPU Switching | NVIDIA Optimus |
| Display | |
| Size | 15.6″ |
| Panel Type | 144Hz |
| IPS-Level | |
| Viewing Angle | 170° / 170° |
| Brightness | 250nits |
| Contrast | 1000:01:00 |
| Colour Gamut | NTSC: 45% |
| SRGB: 62.5% | |
| Adobe: 47.1% | |
| Native Resolution | Full HD(1920×1080) |
| Storage | |
| Installed | 1x 512GB M.2 NVMe PCIe 3.0 SSD |
| Supported | 1x M.2 2280 PCIe 3.0 NVMe SSD (Occupied) |
| 1x M.2 2280 PCIe 3.0 NVMe SSD (Vacant) | |
| Input / Output | |
| Ports | 1x USB 2.0 Type-A |
| 2x USB 3.2 Gen 1 Type-A | |
| Audio | 1x USB 3.2 Gen 1 Type-C support DisplayPort / G-SYNC |
| 1x HDMI 2.0b | |
| 1x 3.5mm Combo Audio Jack | |
| 1x RJ45 Ethernet | |
| Communications | |
| Ethernet | 10/100/1000Mbps Ethernet |
| Wi-Fi | 802.11ax 2×2 Dual-Band WiFi 6 Adapter |
| Bluetooth | Bluetooth v5.2 |
| Integrated Input Devices | |
| Keyboard | RGB Backlit Chiclet Keyboard |
| Pointing Device | Touchpad |
| General | |
| Webcam | 720P HD Camera |
| Microphone | Built-in Array Microphone |
| Operating System | Windows 11 Home |
| Battery | 48WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter | 150W AC Adapter |
| Output: 20V DC, 7.5A, 150W | |
| Input: 100~240V AC, 50/60Hz universal | |
| Speakers | 2-speaker System with Smart Amplifier Technology |
| Audio Tech | DTS Software |
| Chipset | Mobile Intel HM470 Express Chipsets |
| Dimensions | 359mm x 256mm x 24.7mm – 24.9mm |
| Weight | 2.30Kg |
| Warranty Information | |
| Warranty | 1 Year Warranty |
