Description
Part number90IG06L0-MU9R10
-
- New-generation WiFi 6 – Enjoy ultrafast speeds up to 5400 Mbps with 160 MHz WiFi 6 channels
-
- Fully optimized gaming – Mobile Game Mode, dedicated Gaming Port and Gear Accelerator let you optimize any type of gaming on mobile, console or PC
-
- VPN Fusion – Run a VPN and an ordinary internet connection simultaneously, allowing maximum speed even if other network users need to use a VPN
-
- More privacy, anywhere – Instant Guard secures public WiFi connections anywhere in the world using GS-AX5400, with just a click
-
- ASUS AiMesh support – Create a flexible, seamless whole-home mesh network with AiMesh-compatible routers
The First ROG Strix Router: Built to Win!
Get the competitive edge with ROG Strix GS-AX5400, a WiFi 6 gaming router that gives you the fastest, smoothest WiFi gaming connections ever. With ultrafast WiFi speeds up to 5400 Mbps, it’s ready for the most intense matches, and with fully customizable ASUS Aura RGB lighting effects, it looks great too. If you take gaming seriously, you need the GS-AX5400!
WiFi 6 — The Ultimate Gaming Power
Lower Latency | Faster Speeds | Energy Efficiency | Longer Range
WiFi 6 brings incredible speeds and coverage to your gaming network, and supports all your existing devices.*
*To benefit from WiFi 6 features, WiFi 6 clients are required.
Give Your Gaming Top Priority – Gaming Port | – Gear Accelerator | – Game Boost
The dedicated Gaming Port on GS-AX5400 is a special LAN port that automatically prioritizes any wired device connected to it. You don’t need to configure it, just connect your gaming PC or console to the gaming port to put it at the head of the queue for a fast, stable connection.
Easy port forwarding for different NAT types
With easy three-step port forwarding. it’s never been simpler to improve your connection speed, lobby wait times, and overall gameplay — even if the host uses different types of NAT!
One-Tap Boost for Mobile Gaming
Tap to enable Mobile Game Mode in the ASUS Router app on your phone, and you’re ready for full-speed mobile gaming, with minimum lag and latency!
No Limits!
With the amazing VPN Fusion you can run both a VPN and an ordinary internet connection — simultaneously! So even if other network users need to use a VPN, you can still enjoy maximum gaming speeds.
Everyone’s Protected, Always
For total peace of mind, GS-AX5400 includes ASUS AiProtection Pro powered by Trend Micro™, with automatic, regularly updated security signatures to protect all your devices and personal data from internet threats.
Make Free WiFi Secure, Wherever You Are
The free public WiFi you find in coffee shops, restaurants, hotels, airports and so on is rarely secure. ASUS Instant Guard uses VPN technology to create a secure data tunnel to your GS-AX5400, adding rock-solid security to any public WiFi connections you use.
Create a Whole-Home Mesh WiFi System!
ASUS AiMesh combines multiple AiMesh-compatible ASUS routers to create a whole-home mesh WiFi system with centralized control. You can use a single SSID for your entire home network, with seamless coverage and no more dead zones!
| SPECIFICATIONS | |
| Brand | ASUS |
| Series | ROG STRIX AX5400 |
| Model | GS-AX5400 |
| General | |
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6 |
| Product Segment | AX5400 ultimate AX performance : 4804 Mbps 574 Mbps |
| Antenna | 4x External antenna |
| Transmit & Receive | 2.4 GHz 2 x 2 |
| 5 GHz 4 x 4 | |
| Processor | 1.5 GHz tri-core processor |
| Memory | 256 MB Flash |
| 512 MB RAM | |
| Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) |
| Beamforming: standard-based and universal | |
| 1024-QAM high data rate | |
| 20/40/80/160 MHz bandwidth | |
| Ports | 1x RJ45 for Gigabits BaseT for WAN |
| 4x RJ45 for Gigabits BaseT for LAN | |
| 1x USB 3.2 Gen 1 | |
| Button | WPS Button |
| Reset Button | |
| Power Switch | |
| LED Indicator | 1x Power |
| 1x 2.4G | |
| 1x 5G | |
| 1x WAN | |
| Weight | 701.3g |
| Package content | GS-AX5400 Router |
| RJ-45 cable | |
| Power adapter | |
| Warranty card | |
| Quick start guide | |
| Power Supply | |
| AC Input | 110V~240V(50~60Hz) |
| DC Output | 19 V with max. 1.75 A current |
| AiMesh | |
| Features | AiMesh |
| Primary AiMesh router | |
| AiMesh node | |
| Game | |
| Features | Game Boost/acceleration |
| ROG_First | |
| OpenNAT (Game Profile) | |
| Gaming port | |
| AiProtection | |
| Features | AiProtection Pro |
| Router Security Assessment | |
| Malicious site blocking | |
| Two-Way IPS | |
| Infected Device Prevention and Blocking | |
| Parental Control | |
| Features | Parental Control |
| Parental Control Customized Internet schedule | |
| Traffic Control | |
| Maximum Bandwidth limiter rule | 32 |
| Maximum Traditional QoS rule | 32 |
| Traffic analysis period | Daily, Weekly, Monthly |
| Features | Adaptive QoS |
| Bandwidth Monitor | |
| Bandwidth limiter | |
| Traditional QoS | |
| Traffic Monitor | |
| Real-time traffic monitor | |
| Wired Traffic Monitor | |
| Wireless Traffic Monitor | |
| Traffic Analyzer | |
| Website history | |
| Wireless | |
| Wi-Fi Encryption | WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Maximum Guest Network rule | 2.4GHz x3, 5GHz x3 |
| Maximum MAC Filters | 64 |
| Features | IPv6 |
| MU-MIMO | |
| UTF-8 SSID | |
| Guest Network | |
| WPS | |
| Wi-Fi MAC address filter | |
| Wireless scheduler | |
| Wi-Fi Radar | |
| Airtime fairness | |
| Universal beamforming | |
| WAN | |
| Internet connection Type | PPPoE, PPTP, L2TP, Automatic IP, Static IP |
| NAT Passthrough | PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, PPPoE relay |
| Maximum port forwarding rule | 64 |
| Maximum port triggering rule | 32 |
| Features | Explicit beamforming |
| Dual WAN | |
| WAN Aggregation | |
| 3G/4G LTE dongle | |
| Android tethering | |
| Port forwarding | |
| Port triggering | |
| DMZ | |
| DDNS | |
| LAN | |
| Maximum manually assign IP address rule | 64 |
| Features | DHCP Server |
| IGMP snooping | |
| IPTV | |
| LAN Link Aggregation | |
| Manually assign IP address | |
| VPN | |
| Features | VPN Client L2PT |
| VPN Client OVPN | |
| VPN Client PPTP | |
| VPN Server IPSec | |
| VPN Server OVPN | |
| VPN Server PPTP | |
| VPN Fusion | |
| USB Application | |
| File System | HFS , NTFS, vFAT, ext2, ext3, ext4 |
| Features | HDD hibernation |
| Safely Remove disk | |
| AiCloud | |
| Download master | |
| AiDisk | |
| Media Server | |
| Time Machine | |
| Samba Server | |
| FTP Server | |
| Shared Folder privileges | |
| Administration | |
| Maximum Firewall keyword filter | 64 |
| Maximum Firewall network service filter | 32 |
| Maximum Firewall URL filter | 64 |
| Operating system | ASUSWRT |
| Operating mode | Wireless router mode |
| Access point mode | |
| Media bridge mode | |
| Repeater mode | |
| AiMesh node mode | |
| Features | Free OS upgrade |
| Firewall | |
| Wake on LAN (WOL) | |
| SSH | |
| Configuration backup and restore | |
| Diagnosis tools | |
| Feedback system | |
| System log | |
| Warranty Information | |
| Warranty | 3 Year Warranty |
