Description
ModelMCB-CM694-KN5N-S00
Features
Curved Mesh
The top and front panel are entirely mesh, featuring the iconic CM690 curve and Cooler Master’s signature rhombus pattern. The fine mesh on the CM694 achieves optimal airflow while also filtering out dust with a single layer.
Modular Drive Cages
3 Drive Cages can be individually added, removed, or repositioned to make room for longer graphics cards and/or top & front radiators.
Rich Connectivity (I/O Panel)
The dust-proof I/O Panel features rubber shields, 2 x USB 3.0 ports, a USB 3.1 (Gen 2) Type-C port, and a 4 pole headset jack.
| SPECIFICATIONS | |
| Brand | Cooler Master |
| Series | MasterBox |
| Model | MCB-CM694-KN5N-S00 |
| Physical Details | |
| Colour | Black |
| Materials | Steel |
| Plastic | |
| Side Panel | Steel |
| I/O Ports | 1x USB 3.1 Type C |
| 2x USB 3.0 Type A | |
| 1x 3.5mm Combo Audio Port | |
| Motherboard Support | E-ATX (Up To 271mm), ATX, Micro-ATX, Mini-ITX |
| Expansion Slots | 7 |
| Drive Bays | 6x 3.5″ Drive Bays |
| 8x 2.5″ Drive Bays | |
| 2x 5.25″ Drive Bays | |
| PSU Support | ATX Up To 276mm |
| Dimensions | 493 x 220 x 506 mm |
| Weight | 9.4kg |
| Pre-Installed Fans | |
| Front | 2x 120mm |
| Rear | 1x 120mm |
| Fan Support | |
| 120mm | 3x Front |
| 3x Top | |
| 1x Rear | |
| 140mm | 2x Front |
| 2x Top | |
| Radiator Support | |
| 120mm | Front: Up To 360mm |
| Top: Up To 360mm | |
| Rear: Up To 120mm | |
| 140mm | Front: Up To 280mm |
| Top: Up To 280mm | |
| Clearance | |
| Motherboard Tray | Up To 271mm |
| CPU Cooler Height Limitation | Up To 171mm |
| GPU Length Limitation | Up To 410mm (Max.) |
| Up To 350mm (With Stabiliser) | |
| Up To 280mm (With Stabiliser And Drive Cage) | |
| Cable Management | Up To 29mm |
| General | |
| Dust Filters | Top, Front, Bottom |
| Warranty Information | |
| Warranty | 2 Year Warranty |
