Description
n
DESKTOP PERFORMANCE FOR YOUR LAPTOP
n
n
nBoost the performance of your laptop to a desktop gaming PC or workstation with the EG200.
n
nThe EGPU allows the installation of a desktop PCIe graphics card via the ultra high-bandwidth Thunderbolt™ 3 interface, allowing you to increase the GPU performance of any Thunderbolt™ 3 equipped PC or Mac.
n
nFurther expand the usability of your laptop with a dedicated USB hub I/O, hard drive and SSD dock, and a convenient vertical laptop stand.
n
nBoost the performance of your laptop to a desktop gaming PC or workstation with the EG200.
n
nThe EGPU allows the installation of a desktop PCIe graphics card via the ultra high-bandwidth Thunderbolt™ 3 interface, allowing you to increase the GPU performance of any Thunderbolt™ 3 equipped PC or Mac.
n
nFurther expand the usability of your laptop with a dedicated USB hub I/O, hard drive and SSD dock, and a convenient vertical laptop stand.
n
GREATLY BOOST GPU PERFORMANCE
n
n
nAdd the power of a desktop graphics card to your laptop.
n
nThe EG200 interfaces to a laptop with a high-bandwidth Thunderbolt™ 3 connection to greatly increase gaming performance or compute performance with a dedicated graphics card.
n
nAdd the power of a desktop graphics card to your laptop.
n
nThe EG200 interfaces to a laptop with a high-bandwidth Thunderbolt™ 3 connection to greatly increase gaming performance or compute performance with a dedicated graphics card.
n
Part numberTHUNDERBOLT(TM) 3 CONNECTION
n
n
nThe Thunderbolt™ 3 connection supports a blistering speed of up to 40Gbit/s and 60W laptop charging via the USB-C. The EG200 is outfitted with the latest JHL7440 controller to ensure maximum performance and compatibility.
n
nThe Thunderbolt™ 3 connection supports a blistering speed of up to 40Gbit/s and 60W laptop charging via the USB-C. The EG200 is outfitted with the latest JHL7440 controller to ensure maximum performance and compatibility.
n
BUILT-IN LAPTOP STAND
n
n
nNeatly dock your laptop into the space-saving built-in vertical laptop stand and work from directly from an external monitor like a desktop.
n
nNeatly dock your laptop into the space-saving built-in vertical laptop stand and work from directly from an external monitor like a desktop.
n
DEDICATED I/O PORTS
n
n
nThe dedicated USB connection separates the USB hub functionality from the Thunderbolt™ 3 connection to allow the graphics card or other PCI-e device use of the maximum Thunderbolt™ 3 bandwidth.
n
nThe dedicated USB connection separates the USB hub functionality from the Thunderbolt™ 3 connection to allow the graphics card or other PCI-e device use of the maximum Thunderbolt™ 3 bandwidth.
n
HARD DRIVE DOCK
n
n
nExpand the limited storage on your laptop with an added 3.5″ or 2.5″ HDD/SSD drive for your game library or project files.
n
nExpand the limited storage on your laptop with an added 3.5″ or 2.5″ HDD/SSD drive for your game library or project files.
n
SPACE-SAVING COMPACTNESS
n
n
nAt just 9.7L the EG200 is one of the smallest e-GPUs on the market supporting full size cards while saving valuable desktop space.
n
nAt just 9.7L the EG200 is one of the smallest e-GPUs on the market supporting full size cards while saving valuable desktop space.
n
HIGH COMPONENT COMPATIBILITY
n
n
nWith an included 550Watt PSU, the EG200 can support even the most power-hungry graphics cards on the market. Cards with dimensions up to 325 x 54 x 141mm are supported.
n
nAlso compatible with any other PCI-e add-in card such as gigabit ethernet, NVME expansion cards, etc.
n
nWith an included 550Watt PSU, the EG200 can support even the most power-hungry graphics cards on the market. Cards with dimensions up to 325 x 54 x 141mm are supported.
n
nAlso compatible with any other PCI-e add-in card such as gigabit ethernet, NVME expansion cards, etc.
n
ADAPTIVE THERMALS
n
n
nEG200 comes with a built-in temperature sensor. Similar to graphics cards, this allows fans to remain idle under light loads. Should internal case temperatures reach 45°C under heavy load, the fan will activate and ramp up relative to the temperature, keeping your system quiet, yet cool when needed.
nnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn
nEG200 comes with a built-in temperature sensor. Similar to graphics cards, this allows fans to remain idle under light loads. Should internal case temperatures reach 45°C under heavy load, the fan will activate and ramp up relative to the temperature, keeping your system quiet, yet cool when needed.
nnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn
| SPECIFICATIONS | |
| Brand | Cooler Master |
| Series | External Graphics Enclosure |
| Model | MCM-EG200-KNNA55-S00 |
| Chassis | |
| Colour | Black |
| Materials | Steel, plastic, steel mesh |
| Coating | Anodization, Paint |
| Removable Panels | Top, Left, Right |
| Volume | 9.7 litres excluding protrusions |
| Connectivity | |
| GPU | PCIe 3.0 16x physical slot, x16 electrical |
| USB | 3 x USB 3.2 Gen 1 Type-A |
| 1 x USB 3.2 Gen 1 Micro-B | |
| 1 x USB Type-C with Thunderbolt 3.0 | |
| Storage | 1 x SATA 6Gbps 2.5″ or 3.5″ drive slot |
| General | |
| Preinstalled Fans | 1 x 92mm Slim PWM Fan (Up to 2600 RPM) |
| Dimensions | 383 x 208 x 140 mm |
| GPU Clearances | Length: 325 mm |
| Height: 141 mm including PCI PEG connector | |
| Width: 54mm (2.5 slot) | |
| Power Supply | |
| Model | Cooler Master V Gold SFX 550W |
| Power Connectors | 1 x 24-pin ATX |
| 2 x 6 2-pin PCI PEG | |
| 1 x SATA Power | |
| Included Fan | 92 mm Fluid Dynamic Bearing |
| Efficiency | 90% Efficient With Typical Load |
| Operating Temperature | 0° C to 50° C |
| PSU Protections | OVP, OPP, SCP, OCP, UVP, OTP, SURGE AND INRUSH PROTECTION |
| Other | |
| Power Delivery | 60W Max |
| Box Contents | 1 x Cooler Master MasterCase MCM-EG200-KNNA55-S00 |
| 1 x 500 mm Thunderbolt 3.0 Certified Cable | |
| 1 x 700 mm USB Type-A Cable | |
| 1 x USB Type-A to Type-C Adapter | |
| Warranty Information | |
| Warranty | 2 Year Warranty |
