Description
ModelMPE-6501-ACABW-BWO
| SPECIFICATIONS | |
| Brand | Cooler Master |
| Series | MWE Bronze Series |
| Model | MPE-6501-ACABW-BWO |
| Wattage | 650 W |
| Certification | 80 PLUS Bronze EU 230V |
| Modular | Non-Modular |
| Efficiency | 88% @ Typical Load |
| Connectors | |
| ATX 24-Pin Connectors | 1 |
| EPS 4+4-Pin Connectors | 1 |
| EPS 8-Pin Connector | 1 |
| SATA Connectors | 6 |
| Peripheral 4-Pin Connectors | 3 |
| PCI-E 6+2-Pin Connectors | 4 |
| General | |
| Input Current | 10-5A |
| Input Voltage | 200 – 240 Vac |
| Input Frequency Range | 50 – 60 Hz |
| Hold Up Time | >18ms at 100% Full Load@230Vac |
| Fan Size | 120 mm |
| Fan Bearing | HDB |
| Fan Speed | 2,400 RPM |
| Noise Level | @20%: 16.54 dBA |
| @50%: 26.5 dBA | |
| @100%: 42.5 dBA | |
| Power Good Signal | 100 – 500 ms |
| Protection | OVP, OPP, SCP, UVP, OTP |
| Regulatory | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| PFC | Active PFC |
| ATX Version | ATX 12V V2.52 |
| ERP 2014 LOT 3 | Yes |
| MTBF | >100,000 Hours |
| Dimensions | 140 x 150 x 86 mm |
| Warranty Information | |
| Warranty | 5 Year Warranty |
