Description

COOLER MASTER V1200W 80+ PLATINUM FULLY MODULAR ATX PSU BLACK

nThe V1200W 80+ Platinum ATX offers a full modular design that provides more flexible neccessity for the user’s needs. This PSU comes with a 135mm FDB silent fan generates more airflow and less noise. Japanese capacitors offers more stable quality and longer lifespan.
n
nFeatures:
n-Fully modular cable design for easy installation and cable management
n-100% high quality Japanese electrolytic and solid capacitors esnure performance and reliability
n-135mm FDB silent fan default as hybrid mode, equipped with hybrid fan controller, easy switch mode
n-Zero dBA fanless mode silent operation
n-80+ Platinum certified: up to 93% efficiency @50% load
n-Powerful single +12V rail, capable of delivering up to 100A
n-Excellent output voltage stability ensures total voltage regulation under 1%
n-12 PCI-E 6+2pin connectors for 4way SLI & high-end solution builds
n
nSpecifications
n-Type: Intel Form Factor ATX 12V V2.31
n-Dimensions: 150*190*86mm
n-Input Voltage: 100-240Vac
n-Input Current: 15-7.5A
n-Input Frequency Range: 60-50Hz
n-PFC: Active PFC(>0.9)
n-Power Good Signal: 100-500ms
n-Hold Up time: >17ms
n-Efficiency: 93% Typical
n-MTBF: >100,000 hours
n-Protection: OVP / UVP / OPP / OTP / OCP / SCP
n-Output Capacity: 1200W
n-Operation Temperature: 0-40?
n-Regulatory: CE/TUV/TUV-SUDNRTL/FCC/EAC/CCC/BSMI/RCM
n-Fan: Silent FDB 135mm
n
nConnectors:
n-M/B 20+4pin x 1
n-CPU 4+4pin x 2
n-PCI-e 6+2pin x 12
n-SATA x 12
n-4pin peripheral x 9
n-4pin floppy x 1
