Description
BLAZING FAST GEN5 SPEEDS
Harness the power of Gen5 SSD technology with NVMe 2.0 to enable faster read and write times, built with high-density 3D TLC NAND flash memory. PCIe Gen5 x4 combines with the massively high-bandwidth NVMe 2.0 interface to unleash higher-speed data transfers and greater M.2 SSD performance than ever before.
Up to 10,000MB/s Max Sequential Read
Up to 10,000MB/s Max Sequential Write
1TB Capacity
Built to Last
HIGH-DENSITY 3D TLC NAND
Combines high-speed performance with outstanding endurance, ensuring your drive will last and perform well through many years of use.
Easy Installation
COMPACT M.2 2280 FORM-FACTOR
Fits directly onto most motherboards.*
*Select Intel Z690 and Z790 and AMD 600 Series motherboards; lower performance on PCIe Gen4 M.2 motherboards
Faster than Ever
MICROSOFT DIRECTSTORAGE**
Enables the MP700 to communicate directly with your graphics card when playing compatible games, for unbelievably fast load times.
**DirectStorage requires a DirectX12 GPU with Shader Model 6.0 support
| SPECIFICATIONS | |
| Brand | Corsair |
| Series | MP700 Series |
| Model | MP700 1TB (CSSD-F1000GBMP700R2) |
| Controller | Phison PS2026-E26 Controller |
| Flash Technology | 3D TLC NAND Flash Technology |
| Heatsink | N/A (Heatsink recommended) |
| Form factor | M.2 2280 |
| Interface | PCIe 5.0 x4 NVMe |
| Capacity | 1000GB (1TB) |
| DRAM Cache | Yes |
| Performance | |
| Sequential Read Speed | Up to 9.5GB/s |
| Sequential Write Speed | Up to 8.5GB/s |
| 4K Random Read (IOPS) | Up to 1.3 million IOPS |
| 4K Random Write (IOPS) | Up to 1.6 million IOPS |
| Endurance (Total bytes written) | 700 TBW |
| General | |
| Power Consumption (Read) | 10.0W (average) |
| Power Consumption (Write) | 10.0W (average) |
| General | |
| Dimensions | 80 x 23 x 11mm (L x W x H) |
| Weight | 34g |
| MTBF | 1.6 Million hours |
| Colour | Black |
| Platform Support | AMD 600 Series Chipsets with PCIe Gen 5.0 M.2 SSD slots |
| Intel 600 Series & 700 Series with PCIe Gen 5.0 M.2 SSD slots | |
| Backwards compatible with PCIe 4.0 & PCIe 3.0 M.2 SSD slots | |
| PS5 Compatible | N/A |
| Operating System Support | Microsoft Windows 10 or later |
| Software | Corsair SSD Toolbox Software |
| Features | S.M.A.R.T. Status |
| Advanced Garbage Collection | |
| RAID Engine | |
| LDPC Coding | |
| DRAM Cache | |
| AES 256-Bit Encryption | |
| Microsoft Direct Storage Capable | |
| Warranty Information | |
| Warranty | 5 Year Warranty |
