CORSAIR RGB FAN LED HUB for RGB LED FANS FROM CORSAIR – BLACK

Description

Part numberco-8950020

RGB Hubs Done Right

The Corsair RGB Fan Hub is, as the name implies, specialized in the control of the RGB illumination of the fans of the manufacturer Corsair. In each case one of a total of six 4-pin connections can be plugged in, for example, the fans from Corsair’s HD, LL, ML or SP-RGB series. The hub and the RGB LEDs are powered by an integrated SATA connector.

A 3-pin slot on the opposite side connects the hub to Corsair’s Commander Pro RGB LED Controller (LULS-271). Alternatively, the optional wired remote control for Corsair’s RGB fans can be connected to the slot or the Corsair RGB Fan Hub can be connected via an optional cable to a JCORSAIR header on a dedicated motherboard. On the back is an M3 strip that allows the hub to be attached anywhere.

Note: Remote control and cables for connecting to the Corsair Commander Pro RGB LED Controller or to the JCORSAIR header of a motherboard are not included with the package.

Features
Technical details:
– Dimensions: approx. 70 x 50 x 38 mm (L x W x D)
– Weight: approx. 45 g
– Color: Black
Connections:
– 6x 4-pin (for fans)
– 1x 3-pin (for controller / remote control / JCORSAIR header)
– 1x SATA (for power connection)
Compatibility:
– Corsair Commander Pro RGB LED
– HD fan series from Corsair
– LL fan series from Corsair
– ML fan series from Corsair
– Corsair’s SP-RGB fan series
