HIGH AIRFLOW PANELS
Mesh panels surround the CH160 from numerous sides and create a high-airflow, small-form-factor case like no other.
- 083 6088 899
- Mon- Sat from 9 am to 6 pm
sales@rebelgaming.co.za
sales@rebelgaming.co.za
R1299.00 Incl. Vat
(Displayed price above applies to EFT / Bank Transfer payments only.)
Out of stock
KEY FEATURES:
– Vented High Airflow Mini-Tower Chassis
– Designed for Air Cooling
– Clear Tempered Glass Side Panel Window
– Removable Carry Handle for Easy Transport
– Supports Mini-ITX Motherboards
– Supports ATX, SFX, SFX-L Power Supplies
– 1x USB 5Gbps Type-C Port
– 2x USB 5Gbps Type-A Ports
– 1x 3.5mm Combination Audio Jack
– 1x 2.5/3.5″ Combo Drive Bay (Removable, Conflicts with Fan Mount)
– 3x PCI Expansion Slots
– 3x Removable Magnetic Dust Filters
– Supports Up to 4x 120mm Chassis Fans
– No Radiator Support
– CPU Cooler Clearance: 172mm
– GPU Cooler Clearance: Up to 305 x 138 x 65mm (L x W x H)
– PSU Length Clearance: 140mm
– 2 Year Warranty
Overclocker:
B760I + RTX 4070/NVIDIA GeForce RTX 4090(length limit 305mm) + AK620 Series + SFX PSU
SPECIFICATIONS |
|
| Brand | DeepCool |
| Series | CH Series |
| Model | CH160 White (R-CH160-WHNGI0-G-1) |
| Physical Details | |
| Colour | White |
| Materials | Steel |
| Plastic | |
| Tempered Glass | |
| Side Panel | Clear Tempered Glass Side Panel |
| Front I/O | 1x USB 5Gbps Type-C Port |
| 2x USB 5Gbps Type-A Ports | |
| 1x 3.5mm Combination Audio Jack | |
| Motherboard Support | Supports Mini-ITX Motherboards |
| Expansion Slots | 3x PCI Slots |
| Drive Bays | 1x 2.5/3.5″ Combo Drive Bay (Removable, Conflicts with Fan Mount) |
| PSU Support | Supports ATX, SFX, SFX-L Power Supplies |
| Dimensions | 336 x 200 x 283.5 mm (D x W x H) |
| Weight | 3.3kg |
| Pre-Installed Fans | |
| Front | N/A |
| Top | N/A |
| Rear | N/A |
| Fan Support | |
| Front | 1x 120mm Fan (Conflicts with 2.5/3.5″ Drive Bay) |
| Top | 2x 120mm Fans |
| Rear | 1x 120mm Fan |
| Radiator Support | |
| Front | N/A |
| Top | N/A |
| Rear | N/A |
| Clearance | |
| CPU Cooler Height Limitation | 172mm |
| GPU Length Limitation | ATX PSU: 230 x 138 x 65mm (L x W x H) |
| SFX PSU: 305 x 138 x 65mm (L x W x H) | |
| Cable Management | N/A |
| PSU Length Limit | Up to 140mm (ATX) |
| General | |
| Dust Filters | 3x Removable Magnetic Dust Filters |
| Chassis Lighting | N/A |
| Warranty Information | |
| Warranty | 2 Year Warranty |
| Weight | 8 kg |
|---|---|
| Chassis Brand | |
| Chassis Colour | |
| Chassis Form Factor | |
| Chassis Lighting | |
| Chassis Side Panel |
