R1029.00 Incl. Vat
(Displayed price above applies to EFT / Bank Transfer payments only.)
KEY FEATURES:
– 700W total, single +12V 58.3A (699.6W)
– 80 PLUS 230V EU Bronze, Cybenetics Bronze/A- 230V, PPLP Bronze
– ATX12V v2.52, Active PFC + Double Forward + DC-to-DC
-Non-modular (fixed sleeved cables)
– 120 mm HYB long-life fan (≈40,000 hrs MTBF)
– Protections: OPP / OVP / OCP / SCP / OTP / UVP / SIP / NLO
– Hold-up / P.G.: ≥16 ms @ 75% load / 100–150 ms
– Connectors: 24-pin ×1, EPS 4+4-pin ×1, PCIe 6+2-pin ×2, SATA ×6, Molex ×2
– AC Input: 200–240 V AC, 50–60 Hz
– Operating Temp: 0–40 °C
– 3 Year Warranty
Built for stable everyday power, the PF700X delivers 700W on a strong single +12V rail (58.3 A / 699.6 W) with multiple Bronze-level efficiency badges (80 PLUS 230V EU, Cybenetics Bronze / A- 230V, PPLP Bronze). The ATX 2.52 platform uses Active PFC + Double Forward + DC-to-DC and dual-stage EMI filtering for tight regulation and low ripple. A long-life 120 mm HYB fan keeps noise in check, while protection ICs cover OPP/OVP/OCP/SCP/OTP/UVP/SIP/NLO. Comes with fixed (non-modular) sleeved cables and a 3-Year limited warranty.
700W total output, single +12V 58.3 A (699.6 W).
Bronze efficiency: 80 PLUS 230V EU, Cybenetics Bronze/A- 230V, PPLP Bronze (≥88% at 50% load).
ATX 2.52 design with Active PFC + Double Forward + DC-to-DC; dual-stage EMI.
Premium capacitors (Taiwanese + Japanese); ≥16 ms hold-up @ 75% load; 100–150 ms P.G..
120 mm long-life HYB fan, 40,000 hrs MTBF; rated for 0–40 °C operation.
Protections: OPP / OVP / OCP / SCP / OTP / UVP / SIP / NLO.
Cabling: Non-modular fixed sleeved cables for clean installs.
Connectors: 24-pin x1, EPS 4+4-pin x1, PCIe 6+2-pin x2, SATA x6, Molex x2.
Warranty: 3-Year limited warranty.
| Spec | Details |
|---|---|
| Model | PF700X |
| Form factor / Std. | ATX12V v2.52 |
| Efficiency certifications | 80 PLUS 230V EU Bronze, Cybenetics Bronze / A- 230V, PPLP 230V Bronze |
| AC input | 200–240 V AC, 5 A, 50–60 Hz |
| DC output (max) | +3.3 V 18 A, +5 V 18 A (combined 110 W) · +12 V 58.3 A (699.6 W) · -12 V 0.3 A (3.6 W) · +5VSB 3 A (15 W) — Total 700 W |
| Topology | Active PFC + Double Forward + DC-to-DC; dual-stage EMI |
| Capacitors | Taiwanese + Japanese electrolytic |
| Hold-up / P.G. | ≥16 ms @ 75% load / 100–150 ms |
| Cooling | 120 mm long-life HYB bearing fan |
| Protections | OPP / OVP / OCP / SCP / OTP / UVP / SIP / NLO |
| Cabling | Non-modular, fixed sleeved cables |
| Connectors | ATX 24-pin (20+4) ×1 · CPU EPS 4+4-pin ×1 · PCI-E 6+2-pin ×2 · SATA ×6 · 4-pin Peripheral (Molex) ×2 |
| Dimensions (W×L×H) | 150 × 140 × 86 mm |
| Operating temp | 0–40 °C |
| MTBF | 40,000 hrs |
| Warranty | 3-Year limited warranty |
| Weight | 2.5 kg |
|---|---|
| PSU Efficiency Rating | |
| PSU Form Factor | |
| PSU Manufacturer | |
| PSU Modularity | |
| PSU Wattage |
