July 18, 2023Gigabyte AMD B550 VISION D-P AMD4 PCIe 4.0 ATX Motherboard
R7606,00 Incl. Vat
KEY FEATURES:
– ATX Form Factor
– AMD B550 Chipset
– Socket AM4
– 4x DDR4 DIMM Slots, Supports up to 128GB
– Supports up to DDR4-5100
– 3x PCI-E 4.0/3.0 x16 Slots
– 4x SATA 6Gbps Ports, 2x M.2 Slots
– 2x Thunderbolt 3 (USB Type-C, with USB 3.2 Gen 2 Support)
– 3x USB 3.2 Type-A Gen 1, 2x USB 3.2 Type-A Gen 2, 2x USB 2.0/1.1 Type-A
– 1x HDMI, 1x DisplayPort, 5x Audio Jacks
– Intel Wi-Fi 6 AX200
– Intel 2.5GbE LAN Chip
– Realtek 2.5GbE LAN Chip
– Realtek ALC1220-VB Codec
– 3 Year Warranty
Gigabyte AMD B550 VISION D-P AMD4 PCIe 4.0 ATX Motherboard
B550-VISION-D-P
See The Passion of Creation
VISION Series motherboards are built for creator pc. It featured with reliable performance, impressive connectivity, expandable on graphics, and ultra-fast storage for creators to deal with heavy design workloads such as video editing and 3D rendering. It’s the perfect fit for DIY creators to build their own ideal machine.
ECC Memory
Error Correction Code (ECC) memory corrects errors in your data as it passes in and out of memory to ensure reliability for critical applications.
*ECC Memory (ECC mode) support varies by CPU.
Multi-Card Support
Multi-graphics configurations offer better graphics performance for applications which demand the highest frame rates without compromising on resolution.
*Actual support may vary by CPU
More Speed. More Pixels. More Possibilities.
Thunderbolt™ 3 is the single most advanced port available. It uses USB Type-C™ connectors and cables but as a single cable solution, creating one compact port that delivers the fastest connection to any dock display or data device. The only cable you need brings the limitless connectivity with you.
Daisy-Chain Multiple Devices
GIGABYTE Thunderbolt™ motherboards allow users to daisy chain up to 12 devices simultaneously via an incredible bi-directional 40Gbps data pipeline that includes both PCIe and DisplayPort traffic. It redefines desktop PC connectivity to make it far easier to connect multiple high-speed storage devices and HD displays to your PC than ever before..
High-Bandwidth Dual 2.5GbE Connectivity
With both LAN ports designed, you’ll benefit from increased bandwidth for speed, automated load balancing for smoother data flow, and instant failover if anything goes wrong. Adoption of dual 2.5G Ethernet provides an immediate boost to overall network performance, and greatly improves the bandwidth required at large file transfers, video editing, and professional workloads
Make Latency a Thing of the Past
Intel Wireless solution supports 802.11ax, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, fewer dropped connections, and speeds up to 2.4Gbps, Wi-Fi 6 is designed to improve speed, increase efficiency, and reduce congestion in heavy bandwidth usage scenarios.
SuperSpeed USB 3.2 No Hassle Connection
The back panel of B550 VISION D-P features with USB 3.2 Gen2 ports design, which is twice the bandwidth compared to its previous. Be enjoying ultimate connection flexibility and brilliant transfer speeds of up to 10Gbps.
Cooling Technology
Effective cooling solution is essential for a heavy design workload to get away with slow down, crashes, and unexpected shutdown.
Unconventional Heatsinks is designed for better thermal dissipation but also aesthetically appealing to creators. Iconic curved heatsink covers the hottest VRM area to ensure efficient power delivery for stable performance. Creators transfer larger file with un-throttled storage performance by efficient M.2 heatsinks.
Smart Fan 5
Eight hybrid fan headers and numerous temperature sensors are planted on the motherboard to monitor in real time and configure fan mode to fit different workloads via Smart Fan 5. Creators are allowed to set the trigger point to activate the fan and its corresponding speed. The fan completely stops when performing light tasks to avoid noise
PCI Express 4.0 Hardware Design
For most prosumers and content creators, high bandwidth storage and high performance graphics card or accelerator cards are critical for their projects. This is especially true for 3D rendering and creating high resolution textures. To support most cutting edge devices, this motherboard uses the groundbreaking PCIe 4.0 hardware design.
From PCB, several new IC to device connectors, everything that the PCIe 4.0 signal goes is a completely new generation, to make sure your content creation PC is future proof.
PCIe Bandwidth
Up to 31.5GB/s from new PCIe 4.0 x16 slot designs for the next generation add on cards need tremendous bandwidth, including the graphics card, deep learning accelerator card, and the video capture card
SSD Read Speed
Content creators workflows constantly involve huge files, such as images, videos, and 3D models. Time for editing, saving, and transferring those huge files can be substantially reduced with the new generation PCIe 4.0 SSD.
Faster Speed. More Space.
M.2 Drives keep the load times away. Breaking the barriers of SATA limitations. M.2 PCIe SSD gives you X7 faster data transferring experience compared to 2.5″ SATA solid state drives.
Dual NVMe PCIe x4 M.2
M.2, the latest storage technology. GIGABYTE M.2 solution offers considerably faster storage performance and provides an ideal storage with RAID modes. To feature PCIe 4.0*/3.0 x4 and PCIe 3.0 x4 M.2 connectors for offering the best compatibility in terms of NVMe storage for creators who demand high capacity and seek the best performance.
M.2 Ultra Cool
With durability in mind, GIGABYTE provides a thermal solution for M.2 drives. This unique M.2 Thermal Guard prevents throttling and bottlenecks from M.2 devices as it helps to reduce and dissipate heat before it becomes an issue.
Immersive Sounds To Go
DTS:X Ultra is capable of delivering consumers a truly premium entertainment experience by completely surrounding the listener and expanding the sound stage to create a more immersive environment. Supports channel-based, scene based, and object-based audio. Also, it takes movies, music, and interactive gaming experiences to an exciting new level.
Specifications
Make and Model | Gigabyte B550 VISION D-P Motherboard |
---|---|
Part Number | B550 VISION D-P |
CPU | AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors/ New Generation AMD Ryzen™ with Radeon™ Graphics processors (Please refer “CPU Support List” for more information.) |
Chipset | AMD B550 |
Memory | 1. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory 2. 3rd Gen AMD Ryzen™ Processors: Support for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules 3. New Generation AMD Ryzen™ with Radeon™ Graphics processors: Support for DDR4 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules 4. Dual channel memory architecture 5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules 6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules 7. Support for Extreme Memory Profile (XMP) memory modules (Please refer “Memory Support List” for more information.) |
Onboard Graphics | Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors+Intel® Thunderbolt™ 3 Controller: 2 x Intel® Thunderbolt™ 3 connectors (USB Type-C™ ports), supporting DisplayPort and Thunderbolt™ video outputs and a maximum resolution of 5120×2880 @ 60 Hz with 24 bpp * Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™ devices that can be used is dependent on the number of the PCI Express devices being installed. (Refer to Chapter 1-6, “Back Panel Connectors,” for more information.) * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors: 1 x HDMI port, supporting a maximum resolution of 4096×2160 @ 60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB |
Multi-Graphics Technology | Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies |
Audio | 1. Realtek® ALC1220-VB codec * The back panel line out jack supports DSD audio. 2. Support for DTS:X® Ultra 3. High Definition Audio 4. 2/4/5.1/7.1-channel 5. Support for S/PDIF Out |
LAN | Intel® 2.5GbE LAN chip (2.5 Gbit/1000 Mbit/100 Mbit) (LAN1) Realtek® 2.5GbE LAN chip (2.5 Gbit/1000 Mbit/100 Mbit) (LAN2) |
Wireless Communication module | Intel® Wi-Fi 6 AX200 1. WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band 2. BLUETOOTH 5 3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate * Actual data rate may vary depending on environment and equipment. |
Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
1. 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot (PCIEX8), integrated in the CPU: 1. 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x8 mode 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset: 1. Supporting PCIe 3.0 x4 mode |
Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: 4 x SATA 6Gb/s connectors, integrated in the Chipset: |
USB | Integrated in the CPU: 3 x USB 3.2 Gen 1 ports on the back panel 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel Chipset+Intel® Thunderbolt™ 3 Controller: 2 x USB Type-C™ ports on the back panel, with USB 3.2 Gen 2 support Chipset: 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 2 x USB 3.2 Gen 1 ports available through the internal USB header 1 x USB 2.0/1.1 port on the back panel Chipset+2 USB 2.0 Hubs: 5 x USB 2.0/1.1 ports (1 port on the back panel, 4 ports available through the internal USB headers) |
Internal I/O Connectors | 1. 1 x 24-pin ATX main power connector 2. 1 x 8-pin ATX 12V power connector 3. 1 x CPU fan header 4. 1 x water cooling CPU fan header 5. 4 x system fan headers 6. 2 x system fan/water cooling pump headers 7. 2 x addressable LED strip headers 8. 2 x RGB LED strip headers 9. 1 x CPU cooler LED strip/RGB LED strip header 10. 2 x M.2 Socket 3 connectors 11. 4 x SATA 6Gb/s connectors 12. 1 x SATA DOM power connector 13. 1 x front panel header 14. 1 x front panel audio header 15. 1 x USB 3.2 Gen 1 header 16. 2 x USB 2.0/1.1 headers 17. 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) 18. 1 x serial port header 19. 1 x Clear CMOS jumper 20. 2 x temperature sensor headers 21. 1 x Q-Flash Plus button 22. 1 x USB Type-C™ port, with USB 3.2 Gen 1 support |
Back Panel Connectors | 1 x PS/2 keyboard/mouse port 1 x DisplayPort In port 1 x HDMI port 2 x SMA antenna connectors (2T2R) 2 x USB 3.2 Gen 2 Type-A ports (red) 2 x Thunderbolt™ 3 connectors (USB Type-C™ port, with USB 3.2 Gen 2 support) 3 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 2 x RJ-45 ports 1 x optical S/PDIF Out connector 5 x audio jacks |
I/O Controller | iTE® I/O Controller Chip |
H/W Monitoring | 1. Voltage detection 2. Temperature detection 3. Fan speed detection 4. Water cooling flow rate detection 5. Overheating warning 6. Fan fail warning 7. Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. |
BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
Unique Features | 1. Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer 2. Support for Q-Flash Plus 3. Support for Q-Flash 4. Support for Xpress Install |
Bundled Software | Norton® Internet Security (OEM version) cFosSpeed |
Operating System | Support for Windows 10 64-bit |
Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
CPU Socket Type | |
---|---|
CPU Cooling Socket Support | |
Memory Type | |
Motherboard Brand | |
Motherboard Category | |
Motherboard Chipset | |
Form Factor | |
Motherboard Form Factor | |
Motherboard Ram Support |
