Description
Part numberGV-N166TD6-6GD
WINDFORCE 2X COOLING SYSTEM
WINDFORCE 2X cooling system features two 90mm unique blade fans, alternate spinning, one composite copper heat pipe direct touches the GPU and 3D active fans, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
ALTERNATE SPINNING
The GIGABYTE “Alternate Spinning” is the only solution that can solve the turbulent airflow of adjacent fans. Since the adjacent fans rotate in the same direction, the airflow direction is opposite between the fans, which will cause turbulent airflow and reduce heat dissipation efficiency. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
HEAT PIPE DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
COMPOSITE HEAT-PIPE
The composite heat-pipe combines thermal conductivity and phase transition to efficiently manage the heat transfer between two solid interfaces which increases cooling capacity.
BUILT STRONG
EXTREME DURABILITY
The graphics card uses the better power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.
PROTECTION BACK PLATE
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
-
- – Powered by GeForce® GTX 1660 Ti
-
- – NVIDIA Turing™ architecture and GeForce Experience™
-
- – Integrated with 6GB GDDR6 192-bit memory interface
-
- – WINDFORCE 2X Cooling System with alternate spinning fans
-
- – 90mm unique blade fans
-
- – Protection back plate
| SPECIFICATIONS | |
| Brand | Asus |
| Series | GeForce GTX 16 Series |
| Model | GTX 1660 Ti D6 Edition (GV-N166TD6-6GD) |
| Chipset | |
| GPU | GeForce GTX 1660 Ti |
| Chipset Manufacturer | NVIDIA |
| Interface | PCI-E 3.0 |
| Base Clock | 1500 MHz |
| Boost Clock | 1770 MHz |
| CUDA Cores | 1536 |
| GPU Architecture | NVIDIA Turing Architecture |
| Memory | |
| Effective Memory Clock | 12 Gbps |
| Memory Size | 6GB |
| Memory Interface | 192-bit |
| Memory Type | GDDR6 |
| 3D API | |
| DirectX | Microsoft DirectX 12 API |
| OpenGL | 4.6 |
| Vulkan | Vulkan API |
| Connectivity | |
| Ports | 3x DisplayPort 1.4a |
| 1x HDMI 2.0b | |
| HDCP Support | v2.2 |
| Multi-Monitor Support | 4 |
| Maximum Digital Resolution | 7680 x 4320 |
| VR Ready | Yes |
| General | |
| Features | WINDFORCE 2X Cooling System |
| Composite Heat-Pipe | |
| Protective Backplate | |
| Aorus Engine | |
| Game Ready Drivers | |
| NVIDIA Ansel | |
| NVIDIA G-SYNC | |
| NVIDIA GPU Boost | |
| NVIDIA Highlights | |
| NVIDIA GeForce Experience | |
| NVIDIA Encoder | |
| Power Requirements | |
| Recommended Power Supply | 450W |
| Power Connector | 1x 8-Pin |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | Dual Slot |
| Dimensions | 224 x 121 x 40 mm (LxWxH) |
| Warranty Information | |
| Warranty | 3 Year Warranty |
