Description
Part numberGV-N506TWF2OC-8GD
Elevate your 1440 p and 4 K gaming with the Gigabyte GeForce RTX 5060 Ti WINDFORCE OC 8 G (GV-N506TWF2OC-8GD). Built on NVIDIA’s cutting-edge Blackwell architecture, this factory-overclocked card features 4 608 CUDA cores, 4th-gen ray-tracing cores for hyper-realistic lighting, and 5th-gen Tensor cores with DLSS 4 AI upscaling for significant performance gains. Equipped with 8 GB of ultra-fast GDDR7 memory on a 128-bit bus and PCIe 5.0 bandwidth, it delivers instant responsiveness and future-proofed frame rates. Gigabyte’s WINDFORCE 2X OC cooling solution—with two 100 mm alternate-spin fans, composite heat-pipes, and a large copper baseplate—ensures optimal thermal performance while keeping noise levels low. A sleek metal backplate adds rigidity and style, and RGB Fusion 2.0 lets you customize subtle lighting accents to match your build.
Key Features
-
GPU Architecture: NVIDIA Blackwell with 4th-gen RT Cores & 5th-gen Tensor Cores
-
CUDA Cores: 4 608 for high-throughput rendering and compute tasks
-
Factory Overclock: Pre-tuned boost clocks for extra FPS out of the box
-
Memory: 8 GB GDDR7 @ 28 Gbps on a 128-bit interface
-
Cooling: WINDFORCE 2X OC with two 100 mm alternate-spin fans and composite heat-pipes
-
Interface: PCIe 5.0 x16 (electrically x8) for next-gen motherboard compatibility
-
Display Outputs: 3× DisplayPort 2.1 & 1× HDMI 2.1 (up to 4× 8 K or 2× 4 K @ 144 Hz)
-
Durability: Reinforced metal backplate and Ultra Durable™ components
-
Lighting: RGB Fusion 2.0 customizable LED accents
-
Software: AORUS Engine for one-click overclocking, fan-curve tuning, and real-time monitoring
-
Power: Single 8-pin PCIe power connector; typical board power ~200 W
SPECIFICATIONS |
|
| Brand | Gigabyte |
| Series | WINDFORCE Series |
| Model | GeForce RTX 5060 Ti WINDFORCE OC 16G (GV-N506TWF2OC-16GD) |
| Chipset | |
| GPU | GeForce RTX 5060 Ti |
| Chipset Manufacturer | NVIDIA |
| Interface | PCIe 5.0 x8 |
| Base Clock | 2410 MHz |
| Boost Clock | Up to 2587 MHz |
| CUDA Cores | 4608 Cores |
| GPU Architecture | NVIDIA Blackwell |
| Memory | |
| Effective Memory Clock | 28Gbps |
| Memory Size | 8GB |
| Memory Interface | 128-bit |
| Memory Type | GDDR7 |
| 3D API | |
| DirectX | Microsoft DirectX 12.1 Ultimate |
| OpenGL | OpenGL 4.6 |
| Vulkan | Vulkan 1.4 API |
| Connectivity | |
| Ports | 1x HDMI 2.1b |
| 3x DisplayPort 2.1a | |
| HDCP Support | Yes, 2.3 |
| Multi-Monitor Support | Up to 4x simultaneous |
| Maximum Digital Resolution | 7680 x 4320 |
| VR Ready | Yes |
| General | |
| SLI Support | N/A |
| Features | Gigabyte WINDFORCE 2X Cooling System with Hawk Fans |
| Gigabyte AI TOP Utility | |
| Server-Grade Thermal Conductive Gels & Composite Metal Grease | |
| Gigabyte Control Center | |
| NVIDIA Optical Flow Accelerator Technology | |
| 4th Gen Ray Tracing Cores | |
| 5th Gen Tensor Cores | |
| PCI Express Gen 5 | |
| Real-Time Ray Tracing Technology | |
| NVIDIA DLSS 4.0 with Frame Generation and Frame Warp | |
| NVIDIA GeForce Game Ready & Studio Drivers | |
| NVIDIA G-Sync Premium | |
| NVIDIA Reflex 2 | |
| NVIDIA Broadcast | |
| NVIDIA AV1 Encoder | |
| NVIDIA Omniverse 3D Design | |
| NVIDIA Canvas | |
| NVIDIA GPU Boost | |
| NVIDIA Encoder, 9th Generation | |
| NVIDIA Decoder, 6th Generation | |
| Power Requirements | |
| Recommended Power Supply | 650W |
| Power Connector | 1x 8-pin PCI PEG Connector |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | 2 Slot |
| Dimensions | 208 x 120 x 40mm (L x W x H) |
| RGB | N/A |
| Boxed Accessories | Quick guide |
| Warranty Information | |
| Warranty | 3 Year Warranty |
