Gigabyte P650B 650W 80+ Bronze Power Supply
Original price was: R1351.00.R1182.00Current price is: R1182.00. Incl. Vat
Or as low as KEY FEATURES:
– 650W Single +12V Rail
– 120mm Cooling Fan
– Intel ATX 12V v2.31 Form Factor
– 4 x PCIe Connectors
– 6 x SATA Connectors
– 3 x 4-Pin Peripheral Connectors
– Braided Mesh Cables
– 3 Year Warranty
Description
Gigabyte P650B 650W 80+ Bronze Power Supply
GP-P650B
80 Plus Bronze Certified Power Supply
80 Plus certified ensures the better power efficiency. Less power waste reduces the heat and fan noise. P650B can be up to 89% efficiency.n
Reliable Mesh Braided Cable
This P650B PSU provides the best solution for the system builds. The mesh braided cable reduces the clutter and improves the airflow in the case.
-
- High Quality 100% Japanese Electrolytic Capacitors
-
- 120mm Smart Control Fan
-
- 80 Plus Bronze Certified
-
- Single +12V Rail Eases installation
-
- 5 Year Manufacturer Limited Warranty
Features
100% Japanese Capacitors
All capacitors are high quality Japanese Capacitors, known to offer efficient performance with longer life and improved reliability.
* The rated lifetime of the main capacitors is over 20 years, at 25° C/)
Single +12Vdc Rail
A Single +12V rail provides the best power output, stability and compatibility for your hardware. And it is the best design for installations.
120mm Hydraulic Bearing (HYB) Fan
120mm Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.
Additional Information:
Specifications
| Make and Model | Gigabyte 80 Plus Bronze Power Supply | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | GP-P650B | ||||||||||||||||||||||||
| Input | |||||||||||||||||||||||||
| Input Voltage | 100 ~ 240 Vac, 50 / 60Hz | ||||||||||||||||||||||||
| Input Current | 9A Maximum | ||||||||||||||||||||||||
| Efficiency | Up to: 85% Under Typical Load 80+ Bronze Certified |
||||||||||||||||||||||||
| Output | |||||||||||||||||||||||||
Maximum Load
|
|||||||||||||||||||||||||
| Cooling | 120mm Double Ball Bearing Cooling Fan | ||||||||||||||||||||||||
| 80 PLUS® | Yes, 80+ Bronze Certified | ||||||||||||||||||||||||
| PFC | Yes, Active Power Factor Correction >0.9 Typical | ||||||||||||||||||||||||
| MTBF | 100,000+ Hours | ||||||||||||||||||||||||
| Connectors | 1x Motherboard 24 pin (20 + 4) 1x CPU 12 V ATX/EPS (4 + 4 pin) 4x 8 pin (6+2) PCI-E 6x SATA 3x 4 pin Molex 1x 4 pin Floppy |
||||||||||||||||||||||||
| Protection | OCP (Over Current Protection) OPP (Over Power Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) UVP (Under Voltage Protection) |
||||||||||||||||||||||||
| Regulatory | 80 PLUS Bronze certified (up to 85% efficient) ATX12V v2.31 BSMI, CCC, CE, EAC, FCC, KCC, PSE, TCM, TUV, UL |
||||||||||||||||||||||||
| Dimensions (LxWxH) | 140 x 150 x 86mm | ||||||||||||||||||||||||
| Net Weight | N/A | ||||||||||||||||||||||||
Additional information
| PSU Efficiency Rating | |
|---|---|
| PSU Manufacturer | |
| PSU Modularity | |
| PSU Wattage | |
| PSU Form Factor |
