Gigabyte Z690 UD AX DDR4 Intel Z690 Alder Lake LGA1700 ATX DDR4 Motherboard
R5734,00 Incl. Vat
KEY FEATURES:
– ATX Form Factor
– Intel Z690 Chipset
– Intel LGA1700 Socket
– 4x DDR4 DIMM Slots, Up to 128GB
– Supports Up to DDR4-5333MHz (OC)
– 1x PCI-E 5.0 x16, 2x PCI-E 3.0 x16 Slots, 2x PCI-E x1 Slots
– 6x SATA 6Gbps, 3x M.2 Gen4 x4 Slots
– 1x USB 3.2 Gen 2×2 20Gbps Type-C, 1x USB 3.2 Gen 2 Type-A Port
– 4x USB 3.2 Gen 1 Type-A Ports, 4x USB 2.0/1.1 ports
– 1x DisplayPort, 1x HDMI port
– Realtek 2.5GbE LAN Port
– Intel Wi-Fi 6 AX201
– Realtek Audio Codec
– Fully Covered MOSFET Heatsinks
– Integrated IO Shield
– 16+1+2 Direct Digital VRM Design
– 60A Power Stage
– Ultra Durable SMD PCIe 5.0 Armor
– Gigabyte RGB FUSION 2.0
– Q-FLASH Plus Onboard Button
– 3 Year Warranty
Gigabyte Z690 UD AX DDR4 Intel Z690 Alder Lake LGA1700 ATX DDR4 Motherboard
GA-Z690-UD-AX-DDR4
The Gigabyte Z690 UD AX DDR4(rev. 1.0)
Intel® Z690 Motherboard with Phases Digital VRM Design, PCIe 5.0 Design, Ultra Performance VRM Heatsinks, 3 x PCIe 4.0 M.2 with Thermal Guard, 2.5GbE LAN, WIFI6 802.11ax, Rear USB 3.2 Gen 2×2 Type-C®, Q-Flash Plus
Features
-
- Supports 12th Gen Intel® Core™ Series Processors
-
- Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
-
- Direct 16+1+2 Digital VRM Design with 60A Power Stage* and Tantalum Polymer Capacitor
-
- Ultra Performance VRM Heatsinks
-
- Intel® WIFI6 802.11ax 2T2R & BT5.2 with AERO Antenna
-
- Fast 2.5GbE LAN with Bandwidth Management
-
- 3 x Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Enlarged Thermal Guards
-
- SuperSpeed USB 3.2 Gen 2×2 TYPE-C® delivers up to 20Gb/s transfer speeds
-
- RGB FUSION 2.0, supports Addressable LED & RGB LED Strips
-
- Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
-
- Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
Additional Information:
Specifications
| Make and Model | Gigabyte Z690 UD AX DDR4 Motherboard |
|---|---|
| Part Number | Z690 UD AX DDR4 |
| Color | Black |
| CPU | 1. LGA1700 socket: Support for 12th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors (Go to GIGABYTE’s website for the latest CPU support list.) 2. L3 cache varies with CPU (Please refer to “CPU Support List” for more information.) |
| Chipset | Intel® Z690 Express Chipset |
| Memory | 1. Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules 2. 4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory 3. Dual channel memory architecture 4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) 5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules 6. Support for Extreme Memory Profile (XMP) memory modules (Go to GIGABYTE’s website for the latest supported memory speeds and memory modules.) (Please refer “Memory Support List” for more information.) |
| Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: 1. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. 2. 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.) (Graphics specifications may vary depending on CPU support.) |
| Audio | 1. Realtek® Audio CODEC 2. High Definition Audio 3. 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings Playback Device to change the default setting first. Please visit GIGABYTE’s website for details on configuring the audio software. 4. Support for S/PDIF Out * Actual output of digital signals may vary depending on the playback content and software used, and an external DAC is required. |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Intel® Wi-Fi 6 AX201: 1. WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz Dual-Band 2. BLUETOOTH 5.2 3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate * Actual data rate may vary depending on environment and equipment. |
| Expansion Slots | 1. 1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 5.0 standard.) 2. 1 x PCI Express x16 slot, running at x4 (PCIEX4) 3. 1 x PCI Express x16 slot, running at x1 (PCIEX1_4) 4. 2 x PCI Express x1 slots (The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.) |
| Multi-Graphics Technology | Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies |
| Storage Interface | CPU: 1. 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 1. 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 2. 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) 3. 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 Intel® Optane™ Memory Ready |
| USB | 1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support 2. 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header 3. 1 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 4. 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
| Internal I/O Connectors | 1. 1 x 24-pin ATX main power connector 2. 1 x 8-pin ATX 12V power connector 3. 1 x 4-pin ATX 12V power connector 4. 1 x CPU fan header 5. 1 x water cooling CPU fan header 6. 3 x system fan headers 7. 1 x system fan/water cooling pump header 8. 2 x addressable LED strip headers 9. 2 x RGB LED strip headers 10. 3 x M.2 Socket 3 connectors 11. 6 x SATA 6Gb/s connectors 12. 1 x front panel header 13. 1 x front panel audio header 14. 1 x S/PDIF Out header 15. 1 x USB Type-C® header, with USB 3.2 Gen 1 support 16. 1 x USB 3.2 Gen 1 header 17. 2 x USB 2.0/1.1 headers 18. 1 x serial port header 19. 2 x Thunderbolt™ add-in card connectors 20. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 21. 1 x reset button 22. 1 x reset jumper 23. 1 x Q-Flash Plus button 24. 1 x Clear CMOS jumper ＊All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24 |
| Back Panel Connectors | 1. 1 x PS/2 keyboard/mouse port 2. 2 x SMA antenna connectors (2T2R) 3. 1 x DisplayPort 4. 1 x HDMI port 5. 1 x USB Type-C® port, with USB 3.2 Gen 2×2 support 6. 1 x USB 3.2 Gen 2 Type-A port (red) 7. 4 x USB 3.2 Gen 1 ports 8. 4 x USB 2.0/1.1 ports 9. 1 x RJ-45 port 10. 3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | 1. Voltage detection 2. Temperature detection 3. Fan speed detection 4. Water cooling flow rate detection 5. Fan fail warning 6. Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. |
| BIOS | 1. 1 x 256 Mbit flash 2. Use of licensed AMI UEFI BIOS 3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | 1. Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer 2. Support for Q-Flash Plus 3. Support for Q-Flash 4. Support for Xpress Install |
| Bundled Software | Norton® Internet Security (OEM version) Realtek® Gaming LAN Bandwidth Control Utility |
| Operating System | Support for Windows 10 64-bit |
| Form Factor | ATX Form Factor |
| Dimensions | 30.5cm x 24.4cm |
| Weight | N/A |
| CPU Socket Type | |
|---|---|
| CPU Cooling Socket Support | |
| Memory Type | |
| Motherboard Brand | |
| Motherboard Category | |
| Motherboard Chipset | |
| Form Factor | |
| Motherboard Socket Type | |
| Motherboard Form Factor | |
| Motherboard Ram Support |
