Description
Part numberIW-LC-MR24
Rotatable CPU Blockhead
The MR Series features an aluminium rotatable CPU blockhead that’s accented with an alluring ARGB ring. The blockhead can rotate a full 360 degrees to match your build.
Silent Static Pressure Neptune AN120 Fans
The MR Series is armed with the Neptune AN120 fans. These fans offer excellent cooling performance without sacrificing your peaceful area.
FIN-Tastic Heat Dissipation
The high-density microchannel fins and a large radiator heat dissipation area enhances heat conducting efficiency.
Radiator Mounted Pump Design
The pump is mounted into the radiator to suppress noise pollution and reduce vibrations. The high-speed pump quickly returns the liquid back into the cooling loop.
Supports Latest CPU Sockets
The modular, tool-free mounting brackets are designed for simple installation on all the latest CPU sockets, and includes LGA 1700 and AM5.
| SPECIFICATIONS | |
| Brand | InWin |
| Series | MR Series All-In-One Watercoolers |
| Model | MR24 (IW-LC-MR24) |
| Radiator | |
| Radiator Dimensions | 277 × 120 × 27mm (L x W x D) |
| Radiator Material | Aluminum |
| TDP | N/A |
| Pump | |
| Pump Dimensions | 81 x 68 x 39mm (L x W x H) |
| Pump Speed | 4200 RPM ±10% |
| Pump Noise | N/A |
| Pump Connector | 3-pin |
| Pump Rated Voltage | 12 VDC |
| Pump Rated Current | 0.34A |
| Pump Power Consumption | 4.08W |
| Fan | |
| Fan Dimensions | 120 × 120 × 25mm (H x W x D) |
| Fan Speed | 900 to 2200 RPM ±10% |
| Fan Airflow | Up to 60.1 CFM |
| Fan Air Pressure | Up to 2.27 mmAq |
| Fan Noise | ≤ 20.5 dBA |
| Fan Connector | 4-pin PWM |
| Bearing Type | Sleeve Bearing |
| Fan Rated Voltage | 12VDC |
| RGB | |
| RGB Sync | Supports 3rd-party RGB controllers |
| MSI Mystic Light, Gigabyte RGB Fusion, ASUS Aura, ASRock PolyChrome Compatible | |
| LED Type | Addressable RGB LED |
| LED Connector | 3-pin ( 5V-D-G) |
| LED Rated Voltage | 5VDC |
| Socket Support | Intel LGA 2066 / 2011 / 1700 / 1200 / 115x |
| AMD AM5 / AM4 / AM3 / FM2 | |
| Weight | 1.4kg |
| Colour | Black |
| Warranty Information | |
| Warranty | 3 Year Warranty |
