Description
Part numberRTX-4070-Ti-SUPER-16G-GAMING-SLIM
Gaming Unbound
GAMING SLIM series is a thinner variant of GAMING series while maintaining high performance capabilities and aggressive looks.
TRI FROZR 3 Thermal Design
Stay cool and quiet. MSI’s TRI FROZR 3 thermal design enhances heat dissipation all around the graphics card.
Part numberTORX FAN 5.0
Fan blades linked by ring arcs and a fan cowl work together to stabilize and maintain high-pressure airflow.
Copper Baseplate
Heat from the GPU and memory modules is captured by a copper baseplate and then rapidly transferred to Core Pipes.
Keeping the Core Cool
Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate to then spread heat along the full length of the heatsink.
Airflow Control
Airflow Control improves airflow dynamics through the Wave Curved 2.0 and updated deflectors for optimizing the balance between cooling and quieter acoustics.
Unrestricted Cooling
A large airflow vent on the backplate allows exhaust air to pass through directly.
Ray Tracing
The Ada architecture unleashes the full glory of ray tracing, which simulates how light behaves in the real world. With the power of RTX 40 Series and third-gen RT Cores, you can experience incredibly detailed virtual worlds like never before.
Part numberNVIDIA DLSS 3
DLSS is a revolutionary breakthrough in AI graphics that multiplies performance. Powered by the new fourth-gen Tensor Cores and Optical Flow Accelerator on GeForce RTX 40 Series GPUs, DLSS 3 uses AI to create additional frames and improve image quality.
NVIDIA Reflex
NVIDIA Reflex and GeForce RTX 40 Series GPUs deliver the lowest latency and best responsiveness for the ultimate competitive advantage. Built to optimize and measure system latency, Reflex provides faster target acquisition, quicker reaction times, and the best aim precision for competitive games.
| SPECIFICATIONS | |
| Brand | MSI |
| Series | GAMING SLIM Series |
| Model | GeForce RTX 4070 Ti SUPER 16G GAMING SLIM (RTX-4070-Ti-SUPER-16G-GAMING-SLIM) |
| Chipset | |
| GPU | GeForce RTX 4070 Ti SUPER |
| Chipset Manufacturer | NVIDIA |
| Interface | PCIe 4.0 x16 |
| Base Clock | 2340 MHz |
| Boost Clock | Up to 2610 MHz |
| MSI Center Extreme Performance Boost Clock | Up to 2625 MHz |
| CUDA Cores | 8448 Cores |
| GPU Architecture | NVIDIA Ada Lovelace |
| Memory | |
| Effective Memory Clock | 21Gbps |
| Memory Size | 16GB |
| Memory Interface | 256-bit |
| Memory Type | GDDR6X |
| 3D API | |
| DirectX | Microsoft DirectX 12.1 Ultimate |
| OpenGL | OpenGL 4.6 |
| Vulkan | Vulkan RT API |
| Connectivity | |
| Ports | 1x HDMI 2.1a |
| 3x DisplayPort 1.4a | |
| HDCP Support | Yes, 2.3 |
| Multi-Monitor Support | Up to 4 |
| Maximum Digital Resolution | 7680 x 4320 |
| VR Ready | Yes |
| General | |
| SLI Support | N/A |
| Features | MSI GAMING SLIM TRI FROZR Cooling System with TORX 5.0 Fans |
| Ventilated Supporting Metal Back Plate | |
| MSI Afterburner Overclocking Utility | |
| MSI Center Utility | |
| NVIDIA Optical Flow Accelerator Technology | |
| 3rd Gen Ray Tracing Cores | |
| 4th Gen Tensor Cores | |
| PCI Express Gen 4 | |
| Real-Time Ray Tracing Technology | |
| NVIDIA GeForce Game Ready & Studio Drivers | |
| NVIDIA G-Sync Premium | |
| NVIDIA Reflex | |
| NVIDIA Broadcast | |
| NVIDIA AV1 Encoder | |
| NVIDIA Omniverse 3D Design | |
| NVIDIA Canvas | |
| NVIDIA GPU Boost | |
| NVIDIA Encoder, 8th Generation | |
| NVIDIA Decoder, 5th Generation | |
| Power Requirements | |
| Recommended Power Supply | 700W |
| Power Connector | 1x 16-Pin 12VHPWR Connector (or 2x 8-pin PCI PEG Connectors) |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | 2.5-Slot |
| Dimensions | 307 x 125 x 51mm (L x W x H) |
| RGB | Yes, with MSI Mystlic Light RGB Sync |
| Boxed Accessories | 1x MSI PCIe Support Bracket |
| 1x 12VHPWR Adapter Cable | |
| Warranty Information | |
| Warranty | 3 Year Warranty |
