R11510.00 Incl. Vat
(Displayed price above applies to EFT / Bank Transfer payments only.)
KEY FEATURES:
– Boost Clock: Up to 2647 MHz
– MSI Center Extreme Performance Boost Clock: Up to 2662 MHz
– CUDA Cores: 4608 Cores
– 4th Gen Ray Tracing Cores
– 5th Gen Tensor Cores
– NVIDIA Blackwell Architecture
– AV1 Decode / Encode Engines
– Video Memory: 8GB GDDR7
– Memory Clock: 28Gbps
– Memory Bus Width: 128-bit
– 3x DisplayPort 2.1a, 1x HDMI 2.1b Ports
– Multi-Display Capability: 4x Displays
– TWIN FROZR 10 Cooling System with STORMFORCE Fans
– Ventilated Metal Backplate
– MSI Mystic Light RGB Sync
– MSI Center Software
– Supports Windows 11, Linux
– 3 Year Warranty
Take your gaming and content-creation to the next level with the MSI GeForce RTX 5060 Ti GAMING OC (G506T-8GC). Built on NVIDIA’s Blackwell architecture, this card features 4 608 CUDA cores, 4th-gen ray-tracing cores, and DLSS 4 AI upscaling to deliver ultra-smooth frame rates in 1440p and solid 4K performance. With 8 GB of ultra-fast GDDR7 memory on a 128-bit bus, a factory overclock, and PCIe 5.0 support, you’ll enjoy immediate out-of-the-box speed boosts. The GAMING OC’s dual TORX Fan 4.0 cooling, copper heat-pipes, and dedicated airflow control keep temperatures low and noise minimal, while MSI Center software offers one-click overclocking and custom fan profiles.
Key Features
NVIDIA Blackwell GPU with 4th-gen RT cores & 5th-gen Tensor cores
4 608 CUDA cores for high parallel throughput
8 GB GDDR7 @ 28 Gbps on a 128-bit interface
Factory overclocked boost clocks for extra FPS
Dual TORX Fan 4.0 design with Airflow Control fins
Copper heat-pipe cooling for efficient thermal management
PCIe 5.0 x16 interface (electrically x8)
3× DisplayPort 2.1b & 1× HDMI 2.1b outputs (up to 4×8K or 2×4K@144 Hz)
MSI Center: one-click OC, fan curve tuning & RGB Mystic Light
Single 8-pin PCIe power connector; typical board power ~200 W
SPECIFICATIONS |
|
| Brand | MSI |
| Series | GAMING Series |
| Model | GeForce RTX 5060 Ti 8G GAMING OC (G506T-8GC) |
| Chipset | |
| GPU | GeForce RTX 5060 Ti |
| Chipset Manufacturer | NVIDIA |
| Interface | PCIe 5.0 x8 |
| Boost Clock | Up to 2647 MHz |
| MSI Center OC Mode Clock | Up to 2662 MHz |
| CUDA Cores | 4608 Cores |
| GPU Architecture | NVIDIA Blackwell |
| Memory | |
| Effective Memory Clock | 28Gbps |
| Memory Size | 8GB |
| Memory Interface | 128-bit |
| Memory Type | GDDR7 |
| 3D API | |
| DirectX | Microsoft DirectX 12.1 Ultimate |
| OpenGL | OpenGL 4.6 |
| Vulkan | Vulkan 1.4 API |
| Connectivity | |
| Ports | 1x HDMI 2.1b |
| 3x DisplayPort 2.1a | |
| HDCP Support | Yes, 2.3 |
| Multi-Monitor Support | Up to 4x simultaneous |
| Maximum Digital Resolution | 7680 x 4320 |
| VR Ready | Yes |
| General | |
| SLI Support | N/A |
| Features | TWIN FROZR 10 Cooling System with STORMFORCE Fans |
| MSI Center Software | |
| NVIDIA Optical Flow Accelerator Technology | |
| 4th Gen Ray Tracing Cores | |
| 5th Gen Tensor Cores | |
| PCI Express Gen 5 | |
| Real-Time Ray Tracing Technology | |
| NVIDIA DLSS 4.0 with Frame Generation and Frame Warp | |
| NVIDIA GeForce Game Ready & Studio Drivers | |
| NVIDIA G-Sync Premium | |
| NVIDIA Reflex 2 | |
| NVIDIA Broadcast | |
| NVIDIA AV1 Encoder | |
| NVIDIA Omniverse 3D Design | |
| NVIDIA Canvas | |
| NVIDIA GPU Boost | |
| NVIDIA Encoder, 9th Generation | |
| NVIDIA Decoder, 6th Generation | |
| Power Requirements | |
| Total Board Power | 180W |
| Recommended Power Supply | 600W |
| Power Connector | 1x 12V-2×6 16-Pin Connector (or 2x 8-pin PCI PEG Connectors with supplied adapter) |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | 2.5 Slot |
| Dimensions | 247 x 135 x 51mm (L x W x H) |
| RGB | Yes, Supports MSI Mystic Light |
| Weight | 0.768kg |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Weight | 2.5 kg |
|---|---|
| GPU Brand | |
| GPU Chipset | |
| GPU Memory Size | |
| GPU Series | |
| GPU Video Connectors |
