MSI MAG PANO M100R PZ ARGB Micro-ATX Tower White Gaming Chassis
R2413,00 Incl. Vat
KEY FEATURES:
– Panoramic View with 270° reinforced glass design
– Micro-ATX Tower
– Supports: Micro-ATX, Mini-ITX Motherboards
– 1x 2.5″/3.5″ SSD combo bay
– Radiator Maximum Supported Length: Up To 360mm (Top) up to 140mm (Rear)
– CPU Cooler Clearance: 175mm
– Maximum GPU Length: 390mm
– 4 x 120mm ARGB Fans Included
– 2 Year Warranty
MSI MAG PANO M100R PZ ARGB Micro-ATX Tower White Gaming Chassis
A New Turning Point
The MAG PANO M100R PZ WHITE comes with a 270° tempered glass panel paired and is Back-connect motherboard compatible; adding to the aesthetically pleasing and cleanliness of your PC Build while enhancing its overall aesthetics and organization. This MAG PANO M100R PZ WHITE Case offers spectacular ambient illumination with 3x 120mm Reverse-blade ARGB PWM Intake Fans and a 120mm ARGB PWM Exhaust Fan, all pre-installed.
Organize Easily
Supporting Back-connect motherboards not only simplifies the installation process but also makes it easy for cable management. Additionally, it prevents interfering with cables in front of the motherboard, keeping the interior of the case a lot cleaner, and the Velcro Straps help to tie the cables together easily.
Features
Extensive Compatibility
Motherboard support: Micro-ATX (Back-connect and general motherboard compatible) and Mini-ITX (general motherboard compatible).
Maximum Component Clearances:
- CPU Cooler Height: 175mm
- GPU Length: 390mm
- PSU Length: 200mm
Storage Options:
- 1x 2.5″/3.5″ SSD combo bay
- 1x 3.5″ HDD Bay*
* This Bay is unavailable if a 120mm fan is installed in bottom Fan Slot
Extensive Cooling Support
The MAG PANO M100R PZ WHITE pre-installed with 3 x 120 mm Reverse-blade ARGB PWM fans and 1 x 120 mm ARGB PWM fan, other fan cooling options include:
- Top: 3x 120mm or 2x 140mm Fans
- Rear: 1x 120mm or 1x 140mm Fan
- PSU Shroud: 2x 120mm Fans
- Bottom: 1x 120mm Fan*
* This Fan Slot is unavailable if a 3.5″ HDD is installed in the Drive Bay
1-to-4 ARGB-PWM Control Board
The pre-installed 1-to-4 ARGB-PWM control board supports extra ARGB fan connections to the case. It supports intuitive control & lighting profiles through the LED switch button, and is also compatible with the Mystic Light utility via MSI motherboards.
- 3-pin ARGB connector
- 4-pin PWM connector
270° Panoramic Display
This case features a 270° reinforced glass design, providing a panoramic view of the interior without obstructive metal at the corners, ensuring a seamless showcase of internal components.
Assemble for Cable Management
The generous 33mm cable routing space & pre-installed cable Velcro strips make it easy to do have cable management.
Multiple Inlets & Filters
The tool-free top removable design ensures effortless installation, while the bottom of this case features a magnetic dust filter for easy removal and cleaning.
Side I/O Connectivity
The Side I/O panel features a USB 3.2 Gen 2×2 Type-C port for high-speed 20Gbps data bridging when used with a compatible motherboard.
- 1x USB 3.2 Gen 2×2 (20Gbps) Type-C port
- 1x USB 3.2 Gen 1 (5Gbps) Type-A port
- 1x 3.5mm Combo Mic in / Audio out Audio port
- 1x LED Switch Button
- 1x AC Power Button
Specifications
| Product | MSI MSI MAG PANO M100R PZ Micro-ATX Computer Case, White |
|---|---|
| Part Number | MAG PANO M100R PZ WHITE |
| Color | White |
| Motherboard Support | Micro ATX w/ Back-Connect Support Mini-ITX |
| Expansion Slots | 5 |
| Drive Bays | 1x 3.5″ Drive Bay 2x 2.5″ / 3.5″ Drive Bay |
| GPU Length | Up to 390mm |
| CPU Cooler Height | Up to 175mm |
| PSU Length | Up to 220mm (requires removal of 3.5 inch Drive Tray) |
| Fan Slots | Top: 3x 120mm / 2x 140mm Rear: 1x 120mm / 1x 140mm Side: 3x 120mm Bottom: 1x 120mm PSU Shroud: 2x 120mm |
| Preinstalled Fans | Side: 3x 120mm ARGB Reverse-blade Fans Rear: 1x 120mm ARGB Fan |
| Radiator Support | Top: 1x 360 / 240 / 120mm Radiator Slot Rear: 1x 140 / 120mm Radiator Slot |
| Preinstalled Radiators | None |
| Front I/O | 1x USB 3.2 Gen 2×2 (20Gbps) Type-C port 1x USB 3.2 Gen 1 (5Gbps) Type-A port 1x 3.5mm Combo Mic in / Audio out Audio port 1x LED Switch Button 1x AC Power Button |
| Power Supply | Supports ATX Power Supplies up to 220mm (Long Power Supplies may require the permanent removal of the 3.5in Drive Tray) |
| Dimensions | 440 x 235 x 405mm |
| Weight | 11.29 kg |
| Chassis Brand | |
|---|---|
| Chassis Colour | |
| Chassis Form Factor | |
| Chassis Lighting | |
| Chassis Radiator Support | |
| Chassis Side Panel |
