MSI MAG X870E TOMAHAWK MAX WIFI AMD X870E Ryzen AM5 ATX Motherboard
R7691.00 Incl. Vat
Or as low as KEY FEATURES:
– AMD X870E Chipset • High-end AM5 platform
– AM5 Socket • Ryzen 9000 / 8000 / 7000 ready
– DDR5 Memory • Up to 8400+ MT/s (OC)
– PCIe 5.0 x16 • Next-gen GPU support
– 4x M.2 Slots • Gen5 & Gen4 NVMe storage
– WiFi 7 • Ultra-fast wireless networking
– 5GbE LAN • High-speed wired networking
– USB4 Type-C • Up to 40Gb/s connectivity
– 3 Year Warranty
Description
MSI MAG X870E TOMAHAWK MAX WIFI AMD X870E Ryzen AM5 ATX Motherboard
MAG X870E TOMAHAWK MAX WIFI
The MSI MAG X870E TOMAHAWK MAX WIFI is engineered for gamers and power users who demand next-generation performance and reliability. Built on the AMD X870E chipset, it supports Ryzen 9000, 8000, and 7000 series processors, offering a future-ready AM5 platform for gaming, productivity, and AI workloads.
With support for DDR5 memory up to 8400+ MT/s (OC), the motherboard ensures fast data processing and improved system responsiveness. The PCIe 5.0 x16 slot provides full bandwidth for next-generation graphics cards, while multiple M.2 slots—including PCIe Gen5 support—enable ultra-fast NVMe storage performance.
Connectivity is a standout feature, offering USB4 Type-C ports delivering up to 40Gb/s speeds, along with WiFi 7 and 5GbE LAN for cutting-edge networking. MSI’s EZ DIY features such as EZ PCIe Release and EZ M.2 Clip simplify installation and upgrades, making it ideal for both first-time builders and enthusiasts.
The motherboard is built with a durable power design and advanced thermal solutions, ensuring stable performance even under demanding workloads and gaming sessions.
WHY IT’S A GREAT CHOICE:
NEXT-GEN AM5 PERFORMANCE
Supports the latest AMD Ryzen processors, delivering powerful performance and future upgrade flexibility.
FAST DDR5 MEMORY SUPPORT
High-speed DDR5 enhances system responsiveness and multitasking efficiency.
FUTURE-READY EXPANSION
PCIe 5.0 graphics and Gen5 NVMe storage ensure compatibility with next-generation hardware.
ADVANCED CONNECTIVITY
USB4, WiFi 7, and 5GbE LAN provide ultra-fast data transfer and networking.
DURABLE GAMING DESIGN
Built with strong VRM and thermal solutions for stable, long-term performance.
SPECIFICATIONS:
| Feature | Details |
|---|---|
| Brand / Model | MSI MAG X870E TOMAHAWK MAX WIFI |
| Form Factor | ATX |
| Socket | AM5 |
| Chipset | AMD X870E |
| CPU Support | AMD Ryzen 9000 / 8000 / 7000 Series Processors |
| Memory Support | 4 x DDR5 DIMM Slots, Dual Channel, Up to 256GB |
| Memory Speed | DDR5 up to 8400+ MT/s (OC) |
| Memory Profile Support | AMD EXPO |
| Expansion Slots | 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16 (x4), 1 x PCIe 3.0 x16 (x1) |
| M.2 Storage | Up to 4 x M.2 Slots (PCIe 5.0 & PCIe 4.0) |
| SATA Storage | 4 x SATA 6Gb/s |
| USB4 | 2 x USB4 Type-C (40Gb/s) |
| Rear USB | USB4, USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0 |
| Video Output | HDMI, USB-C DisplayPort (DP Alt Mode) |
| LAN | 5GbE LAN |
| WiFi | WiFi 7 (802.11be) |
| Bluetooth | Supported (module dependent) |
| Audio | HD Audio, S/PDIF Out |
| Power Design | 14+2+1 Phase Duet Rail Power System |
| Cooling | Extended Heatsinks, M.2 Shield Frozr, Thermal Pads |
| Internal Headers | USB headers, fan headers, RGB headers, front panel connectors |
| BIOS | UEFI BIOS, Flash BIOS Button |
| Special Features | EZ PCIe Release, EZ M.2 Clip, EZ Antenna, AI LAN Manager |
| Operating System | Windows 11 64-bit |
| Warranty | 3 Years |
