MSI PRO B850-P WIFI AMD AM5 ATX Motherboard

MSI PRO B850-P WIFI AMD AM5 ATX Motherboard

Name: MSI PRO B850-P WIFI AMD AM5 ATX Motherboard
Brand: MSI
SKU: PRO B850-P WIFI
Price: 5070.00 ZAR
Availability: OutOfStock

R5070.00 Incl. Vat

KEY FEATURES:

– ATX Motherboard with AMD B850 chipset & AM5 socket

– Supports AMD Ryzen 7000 / 8000 / 9000 Series CPUs

– Supports DDR5 up to 8200+ MHz (OC), up to 256GB, AMD EXPO & Intel XMP 3.0 ready

– Expansion Slots: 1x PCIe 5.0 x16, 1x PCIe 4.0 x16, 2x PCIe 3.0 x1

– Storage: 1x M.2 PCIe 5.0, 2x M.2 PCIe 4.0, 1x M.2 PCIe 4.0 x2, 4x SATA 6Gb/s

– 2x USB 10Gbps Type-C, 2x USB 10Gbps Type-A, 1x USB 5Gbps Type-A, 4x USB 2.0 Type-A

– Display Output: 1x HDMI 2.1

– Networking: 5Gb LAN + WiFi 7 + Bluetooth 5.4

– Audio: Realtek HD Audio

– Power Design: 12+2+2 Duet Rail with premium power stages

– Cooling: M.2 Shield Frozr II with EZ M.2 Clip II, extended heatsinks

– Extra Features: PCIe quick-release, BIOS Flash Button, MSI Center software

– Warranty: 3 Years

Out of stock

SKU: PRO B850-P WIFI Categories: Components, AM5, AMD Mobo, B850, Motherboards, Msi Tags: AM5, AMD, ATX, B850, Motherboard, MSI, Pro B850-P

Description

MSI PRO B850-P WIFI MOTHERBOARD

This MSI PRO B850-P WIFI offers a simple design with a harmonious silver color scheme that perfectly matches both white and black PC builds. It is engineered with many exclusive features of MSI, a true Wi-Fi 7 with EZ Antenna, 5G LAN, PCIe 5.0 M.2 with EZ M.2 Shield Frozr II, and Supplemental PCIe Power, ready for the AMD Ryzen™ 9000 series processors.

Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Supports DDR5 Memory: Dual Channel DDR5 8200+ MT/s (OC)
Ultra Performance: 12+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper and server-grade level material
Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II, EZ Antenna
Lightning Fast Game Experiences: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
5G LAN with Wi-Fi 7 Solution: the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience

Compatibility

Processor Support:

Supports AMD Ryzen™ 9000 / 8000 / 7000 Desktop Processors For Socket AM5.

Operating System Support:

Supports Windows® 11, 64-bit

Specifications

Make and Model	MSI PRO B850-P WIFI Motherboard
Part Number	PRO B850-P WIFI

Operating System	Supports Windows® 11 / 10, 64-bit

Chipset	AMD B850 Chipset
CPU Support	Supports AMD Ryzen™ 9000 / 8000 / 7000 Desktop Processors For Socket AM5

Memory	4x DDR5 DIMM RAM Sockets support non-ECC, un-buffered RAM Sticks 256GB Maximum RAM (4x 64GB) Supports Stock Clocked DDR5 RAM: Up to DDR5-5600 Supports Overclocked DDR5 RAM: Up to DDR5-8200+ • 1DPC 1R Max speed up to 8200+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* * CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility.

Expansion Slots	Ryzen™ 9000 / 7000 Series Processors: PCI_E1 Gen PCIe 5.0 x16 PCI_E2 Gen PCIe 3.0 x1 PCI_E3 Gen PCIe 4.0 x4 PCI_E4 Gen PCIe 3.0 x1 Ryzen™ 8700/ 8600/ 8400 Series Processors: PCI_E1 Gen PCIe 4.0 x8 PCI_E2 Gen PCIe 3.0 x1 PCI_E3 Gen PCIe 4.0 x4 PCI_E4 Gen PCIe 3.0 x1 Ryzen™ 8500/ 8300 Series Processors: PCI_E1 Gen PCIe 4.0 x4 PCI_E2 Gen PCIe 3.0 x1 PCI_E3 Gen PCIe 4.0 x4 PCI_E4 Gen PCIe 3.0 x1 * PCI_E2, PCI_E3 & PCI_E4 share the bandwidth, so the PCI_E3 slot will run at x2 speed when installing devices in the PCI_E2 or PCI_E4 slot.

Onboard Graphics*	1x HDMI v2.1 port, up to 4K UHD @ 60Hz Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Storage	3x M.2 Connector Slots: Ryzen™ 9000 / 7000 Series Processors: M.2_1 PCIe 5.0 x4 supports 2280 / 2260 devices M.2_2 PCIe 4.0 x4 supports 22110 / 2280 devices M.2_3 PCIe 4.0 x2 supports 2280 / 2260 devices Ryzen™ 8700 / 8600 / 8400 Series Processors: M.2_1 PCIe 4.0 x4 supports 2280 / 2260 devices M.2_2 PCIe 3.0 x4 supports 22110 / 2280 devices M.2_3 PCIe 4.0 x2 supports 2280 / 2260 devices Ryzen™ 8500 / 8300 Series Processors: 1x NVMe M.2 PCIe 4.0 x4 Slot 1x NVMe M.2 PCIe 3.0 x2 Slot 1x NVMe M.2 PCIe 4.0 x2 Slot M.2 NVMe storage slots support RAID 0 and RAID 1 4x SATA 6Gb/s Connectors

USB	Rear USB Ports: 2x USB 3.2 Gen 2 (10Gbps) Type-C ports 1x USB 3.2 Gen 2 (10Gbps) Type-A port (Red) 1x USB 3.2 Gen 1 (5Gbps) Type-A port (Blue) 4x USB 2.0 (480Mbps) ports Internal USB Connectors: 1x USB 3.2 Gen 1 (5Gbps) Type-C port via 1x USB Header 4x USB 3.2 Gen 1 (5Gbps) Type-A ports via 2x USB Headers 4x USB 2.0 (480Mbps) Type-A ports via 2x USB Headers

LAN	Realtek® 8126VG LAN Chipset: 1x RJ45 5.0Gb Ethernet LAN port
Wireless Communication	Wi-Fi 7* Wireless Chipset: IEEE 802.11 be/ax/ac/n/g/b/a TriBand (2.4 / 5 / 6GHz) Supports MU-MIMO TX/RX (320MHz) up to 5.8Gbps 2x Rear Antenna Jacks Wi-Fi 7 use requires Windows 24H2 Update or later Windows 11 w/ 21H2 / 22H2 or 23H2 updates only support up to Wi-Fi 6E./
Bluetooth	Wi-Fi 7 Wireless Chipset: Bluetooth v5.4* w/ MLO, 4KQAM Bluetooth v5.4 requires Windows 24H2 Update or later

Audio	7.1 Channel Audio Codec: 2 / 4 / 5.1 / 7.1 Channel High Definition Audio 3x Rear 3.5mm Audio jacks 1x S/PDIF Digital Audio jack

Back Panel I/O	2x USB 3.2 Gen 2 (10Gbps) Type-C ports 1x USB 3.2 Gen 2 (10Gbps) Type-A port (Red) 1x USB 3.2 Gen 1 (5Gbps) Type-A port (Blue) 4x USB 2.0 (480Mbps) ports 1x HDMI v2.1 port 1x RJ-45 2.5Gbe LAN port 2x Rear 3.5mm Audio jacks 1x S/PDIF Digital Audio jack 2x SMA Antenna Connectors (2×2) Flash BIOS Button Clear CMOS Button

Internal I/O Connectors	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 1x USB 3.2 Gen 1 (5Gbps) Type-C port via 1x USB Header 4x USB 3.2 Gen 1 (5Gbps) Type-A ports via 2x USB Headers 4x USB 2.0 (480Mbps) Type-A ports via 2x USB Headers

Form Factor	ATX Form Factor

Dimensions (LxW)	304.8 x 243.8mm
Weight	N/A

Additional information

Weight	2 kg
Motherboard Brand	Msi
Motherboard Category	AMD
Motherboard Chipset	B850
Motherboard Form Factor	ATX
Motherboard Ram Support	DDR5
Motherboard Socket Type	AM5
