Description
One Button to boost Wi-Fi Range
AP5 has a “Range Extender” button, which allows users to boost existing Wi-Fi Range simply by pressing the “Range Extender” button.
Flexible deployment
Wall-Mount design and power over ethernet cable supported make it flexible to deploy in place without power outlet such as garage,warehouse etc.
Multi Operating Modes for Various Scenarios
Multi operating modes including AP,Universal Repeater,WISP(Client+Router), Station(client) help you to boost WiFi range in various scenarios such as large house,villa, eatery,stores, community network.
Excellent Wi-Fi Coverage
Adopt of high power technology and three high gain antennas for better Wi-Fi signal and maximum coverage.
Easy to Manage With AP Controller
AP5 can be managed by the AP controller, like M3 from Tenda. When you deploy multi APs in networks, you can configure SSID(Wireless network name), Channel, Security Key, Output power etc option through M3 in a single location.
Specifications
| Dimension | 148*146.2*31.5mm |
| Standard & Protocol | IEEE 802.11n/g/b |
| Interface | 2 * 10/100M Ethernet Port (RJ45) |
| Antenna | 3*5dBi Detachable Omni Directional (RP-SMA) |
| Button | 1*Reset 1*Range Extender |
| Power Method | DC 12V=1A Passive PoE |
| Passive PoE power supply | Up to 40 meters Passive PoE is supported(cat5e or up) |
| Reception Sensitivity | b mode： 1M -89dBm@8% 11M -87dBm@8% PER g mode： 54M -74dBm@8% PER； n mode： 72.2M -74dBm@8% PER 150M -72dBm@8% PER |
| LED | SYS,WPS,Bridge,WiFi,LAN1,LAN2 |
| Hardware Deployment | Desktop/Wall Mount |
| Frequency Range | 2.4GHz-2.483GHz |
| LAN Settings | Static IP Dynamic IP |
| DHCP Server | DHCP Server Clients list |
| Wireless Rate | 11n: Up to 300Mbps(dynamic) 11g: Up to 54Mbps(dynamic) 11b: Up to 11Mbps(dynamic) |
| Operating Mode | Access Point Universal Repeater Station(Client) WISP (Client + Router) Client + AP |
| Wireless Function | 8 SSID Enable/Disable Wireless Radio Broadcast SSID SSID Hidden automatically when exceed client limit Client limit for SSID Transmission output power AP isolation RSSI threshold for wireless clients WMM capable APSD capable Access control based mac address Wireless Client list VLAN for multi SSID |
| Wireless Security | 64/128 WEP WPA-PSK WPA2-PSK WPA&WPA2-PSK WPA WPA2 |
| Video user capacity | 5 |
| Wireless users capacity | 20+ |
| Diagnostic | Wireless site survey Ping Traceroute |
| Network Service | Schedule Reboot Http/Https |
| Managed by AC | AC500 |
| Package Content | 300Mbps Wireless N High Power Access Point AP5 1*PoE Injector 1*Quick Installation Guide 1*Ethernet cable 1*Power Adapter 2*Screws 2*Plastic Bolt |
| Management Tool | Reboot Restore to factory default System Log Firmware update Time&Date Setting Backup/Restore Configuration Username Managerment |
| Temperature | Operating Temperature:-10℃~45℃ Storage Temperature: -30℃~70℃ |
| Humidity | Operating Humidity:10%~90% non-condensing Storage Humidity:5%~90% non-condensing |
| Default Settings | IP Address: 192.168.0.254 Login Username: admin Login Password: admin |
| Certification | FCC/CE/Rohs/VoC |
