Description
Extraordinary heat dissipation A housing made of 0.8 mm galvanized industrial-grade steel plates for excellent durability, heat dissipation performance, ensuring stable switch operation, a long service life, and more reliable outdoor security surveillance.
Stay connected for 7×24 5 * 10/100Mbps auto-negotiation RJ45 ports that support line-speed forwarding and large-capacity cache, ensuring smooth surveillance video playback and stable data transmission for 7×24.
User-friendly design RJ45 ports and LED indicators are located on the same side and aligned vertically for more intuitively showing network status. The RJ45 ports and the power port are designed in the same orientation to reduce the mounting space requirement, allowing the switch to fit into the slimmest outdoor weak current box.
Product Link
| SPECIFICATIONS | |
| Brand | Tenda |
| Series | 5-Port Desktop Switch |
| Model | TEF1005D |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| LED Indicator | 1x Power |
| 5x Link/Act | |
| Interfaces | 5x 10/100 Base-TX Ethernet ports (Auto MDI/MDIX) |
| Transmission Media | Recommended: CAT5/5e UTP or Better |
| Dimensions | 100.0mm x 64.0mm x 23.0mm |
| Material | Metal |
| Level of Protection | ESD: |
| Air discharge: ±8kV | |
| Contact discharge: ±6kV | |
| Forwarding Mode | Store-and-forward |
| Switch Capacity | 1 Gbps |
| Packet Forwarding Rate | 0.74 Mpps |
| Buffer | 448K |
| MAC Address Table | 1K |
| Power | Input: 100-240V AC 50/60Hz |
| Output: 5.0V 0.6A (External Power Adapter) | |
| Power Consumption | Max: <1.6W |
| Mounting | Desktop mounting: support |
| Wall mounting: support | |
| Rack mounting: non-support | |
| Environment | Operating temperature: 0°C – 45℃ |
| Storage temperature: -40°C – 70°C | |
| Operating humidity: (10% – 90%) RH, non-condensing | |
| Storage humidity: (5% – 90%) RH, non-condensing | |
| Certification | CE, FCC, RoHS |
| Warranty Information | |
| Warranty | 3 Year Warranty |
