Description
Part numberPS-TPD-1200FNFAGE-4
Toughpower GF3 1200W Gold – TT Premium Edition
PCIe Gen 5.0 Ready! Designed with a native PCIe 12+4pin modular connector, the Toughpower GF3 series is built for the next-gen PCIe 5.0 graphics cards and is compatible with Intel ATX 3.0 specifications. The fully modular Toughpower GF3 series comes in 1650W, 1350W, 1200W, 1000W, 850W and 750W and is built to deliver 80 PLUS Gold efficiency. Aimed at providing the best performance, the Toughpower GF3 1200W includes all the critical features such as < 30mV low ripple noise design, extremely strict voltage regulation < ±2%, hold up time> 17 milliseconds, and comes with 100% high quality Japanese capacitors and other premium components to help deliver continuous and stable power.
Fully Compatible With Intel PSDG ATX 3.0 Specifications
Toughpower GF3 series is fully compatible with Intel ATX 3.0 Specifications which supports up to 200% power excursion, reaches 70% low load efficiency and complies with required power supply timing standards. The GF3 series can sustain up to 3x GPU power excursion and 2x total power excursion.
Made to Comply with the Latest Graphics Cards
As the power consumption of graphics cards has increased, so has their demand for power. The GF3 series is designed to support NVIDIA and AMD graphics cards, ready to supply the graphics card according to their different ways of connections.
PCIe Gen 5.0 Ready
Toughpower GF3 1200W Gold comes with a 16pin connector to offer powerful and stable performance allowing the PSU to run next-generation GPUs naturally.
Please follow the recommended power requirements from the GPU manufactures before using the 12VHPWR cable.
Ultra Quiet Smart Zero Fan
Designed with our Smart Zero Fan, the fan will not spin until the load exceeds 30% of the power supply, minimizing the fan noise.
＜30mV Low Ripple Noise Design
Top-end build quality with low ripple noise. All ripples are lower than 30mV on +12V, +5V or +3.3V from 0% to 100% load to ensure a stable operation and keep your performance-critical components to function reliably for longer.
Extremely Strict Voltage Regulation ＜±2%
The voltage regulation, more strict than Intel’s standard +5%,-7% for major rails and ±10% for -12V, is set to no more than ±2% for major rails, providing steady clean power through exceptional voltage stability.
Fully Modular Low-Profile Flat Cable
Offers cable selection for users while powering the system at an advantageous voltage. Low-profile flat black cable makes cable management easier, reduces clutter and increases airflow inside the chassis.
100% High Quality Japanese 105°C/221°F Capacitors
Providing great durability as well as offering the highest stability, while remaining reliable.
High Amperage Single +12V Rail & High-Class Technologies
Powerful single +12V rail can properly deliver the power you need for the best compatibility. The use of LLC and DC to DC circuit design provides very stable operation and enhanced voltage regulation.
| AC INPUT | Input Voltage: 100V-240V~ | ||||
| Input Current: 15.0A / 7.0A | |||||
| Frequency: 50-60Hz | |||||
| DC OUTPUT | +3.3V | +5V | +12V | -12V | +5Vsb |
| Max Output Current | 22A | 22A | 100A | 0.3A | 3.0A |
| Max Output Power | 120W | 1200W | 3.6W | 15W | |
| Total Power | 1200W | ||||
Fluid Dynamic Bearing fan
Featuring a 135mm fluid bearing fan to guarantee superior cooling performance.
80 PLUS Gold Certified and Intel C6/C7 States Ready
Tough power GF3 series saves energy through its high energy efficiency up to 90% and is certified to 80 PLUS® Gold. The series has been optimized to work with all generations of Intel’s processors to achieve maximum energy saving.
CYBENETICS – EFFICIENCY LEVEL CERTIFICATION – GOLD & PLATINUM
Toughpower GF3 1200W is certified to CYBENETICS GOLD in 115V input and PLATINUM in 230V input in terms of efficiency level. The overall efficiency rating is defined as ≥87% to ＜89% of 115V input and ≥89% to ＜91% of 230V input. There are six ETA certifications, covering an efficiency range from 82%. Besides the overall efficiency of a PSU, ETA also takes into account its overall Power Factor readings along with the efficiency of the 5VSB rail and the power that the unit consumes in standby (also called phantom power).
CYBENETICS – NOISE LEVEL CERTIFICATION – STANDARD
Toughpower GF3 1200W is certified to CYBENETICS STANDARD in terms of the noise level. There are seven noise level certifications, covering from dead silent PSUs (＜15db[A]) to quiet noisy ones(>40 db[A]). We use a solid methodology and states of the art equipment to measure the noise that a PSU outputs throughout its entire operation range, from almost zero noise output to full load.
| SPECIFICATIONS | |
| Brand | Thermaltake |
| Series | ToughPower Series |
| Model | Toughpower GF3 1200W |
| ATX Version | ATX12V 3.0 |
| Modularity | Fully Modular |
| Continuous Power | 1200W |
| MTBF | 100,000 Hours (Minimum) |
| Certifications | 80 Plus Gold Certified |
| Cybenetics Gold 230V Certified (22PS2073A) | |
| Cybenetics Standard Plus Noise Rated (22PS2073A) | |
| Performance | |
| Power Good Signal | 100 – 150 milliseconds |
| Hold Up Time | > 17msec at 100% of full load |
| Operating Temperature | 0°C to + 40°C |
| Operating Humidity | 20% to 90%,non-condensing |
| Protections | OCP, OVP, UVP, OPP, SCP, OTP |
| Multi-GPU Ready | Yes |
| Cables | 1x 24-Pin ATX 12V Cable (600mm) |
| 1x 8-Pin EPS 12V CPU Cable (700mm) | |
| 1x 8-Pin (4+4) EPS 12V CPU Cable (700mm) | |
| 1x 12VHPWR PCIe Gen 5 16-pin Cable (500mm) | |
| 2x 8-Pin (6+2) PCIe Twin-Head Cables (500 + 150mm) | |
| 3x SATA 1-to-4-Head Cable (500 + 150 + 150 + 150mm) | |
| 1x Peripheral 1-to-4-Head Cable (500 + 150 + 150 + 150mm) | |
| 1x Floppy adapter Cable (100mm) | |
| Fan | |
| Fan Size | 135mm |
| Bearing Technology | Fluid Dynamic Bearing |
| Zero RPM Mode | Yes |
| General | |
| Form Factor | ATX |
| Dimensions | 160 x 150 x 86mm (D x W x H) |
| Weight | 1.88kg |
| Colour | Black |
| Safety Certifications | CE/UKCA/cTUVus/TÜV/FCC/IC/BSMI/EAC/CB/CCC |
| Warranty Information | |
| Warranty | 10 Year Warranty |
