Description
Part numberPF650L-HE
The DeepCool GamerStorm PF650L 650W Power Supply provides stable power delivery for mainstream gaming PCs, home computers and productivity systems. Designed around the ATX12V 2.31 standard, it combines practical energy efficiency, dependable electrical performance and essential protection features in a compact ATX design.
With 80 PLUS 230V EU Standard certification, the PF650L achieves at least 85% efficiency at 50% load, helping reduce wasted electricity and heat generation. Its Active PFC and double-forward topology support stable power delivery, while the 600W +12V output provides power for demanding components such as processors and compatible dedicated graphics cards.
Cooling is handled by a 120mm sleeve bearing fan, designed to maintain suitable operating temperatures during everyday use. The PF650L incorporates electrolytic capacitors and provides a rated hold-up time of at least 16ms at 75% load, supporting power stability during brief interruptions.
For additional hardware protection, the PF650L includes Over Voltage, Under Voltage, Short Circuit, Over Power and Surge/Inrush Protection, together with No Load Operation support. These safeguards help protect connected components against common electrical abnormalities.
The compact 150 × 140 × 86mm chassis fits standard ATX power supply mounting positions in compatible cases. With motherboard, CPU, PCIe, SATA and peripheral power connectors, the DeepCool GamerStorm PF650L provides a practical solution for everyday desktop and compatible gaming configurations.
WHY IT’S A GREAT CHOICE
– Practical 650W Power Output: Provides a suitable power foundation for mainstream gaming and everyday desktop systems.
– Improved Energy Efficiency: 80 PLUS 230V EU Standard certification helps reduce wasted energy and heat during normal operation.
– Dedicated Graphics Card Support: The 600W +12V output and dual PCIe 6+2-pin connectors accommodate compatible dedicated graphics cards.
– Essential Electrical Protection: Multiple safeguards help protect connected components against voltage abnormalities, short circuits and power-related faults.
– Effective Cooling: The integrated 120mm fan helps maintain suitable operating temperatures during extended system use.
– Broad Case Compatibility: Its compact 140mm length makes installation straightforward in many ATX-compatible PC cases.
– Long-Term Peace of Mind: A 100,000-hour MTBF rating and 3-year limited manufacturer warranty provide additional confidence.
SPECIFICATIONS
| Specification | Details |
|---|---|
| Brand | DeepCool |
| Sub-Brand | GamerStorm |
| Series | PF-L Series |
| Model | PF650L |
| Manufacturer Part Number | PF650L-HE |
| Product Type | ATX Power Supply |
| Rated Power Output | 650W |
| Power Supply Standard | ATX12V V2.31 |
| Efficiency Certification | 80 PLUS 230V EU Standard (White) |
| Efficiency | ≥85% at 50% Load |
| Input Voltage | 200–240V AC |
| Input Current | 5A |
| Input Frequency | 50–60Hz |
| Power Factor Correction | Active PFC |
| PSU Topology | Active PFC + Double-Forward |
| Capacitors | Chinese Electrolytic Capacitors |
| +3.3V Rail | 15A |
| +5V Rail | 15A |
| +12V Rail | 50A |
| -12V Rail | 0.3A |
| +5VSB Rail | 2.5A |
| Combined +3.3V / +5V Output | 100W |
| Maximum +12V Output | 600W |
| Maximum -12V Output | 3.6W |
| Maximum +5VSB Output | 12.5W |
| Total Power Output | 650W |
| Cooling Fan | 120mm |
| Fan Dimensions | 120 × 120 × 25mm |
| Fan Bearing | Sleeve Bearing |
| Motherboard Connector | 1 × 20+4-Pin ATX |
| CPU Power Connectors | 2 × 4+4-Pin EPS |
| PCIe Power Connectors | 2 × 6+2-Pin PCIe |
| SATA Power Connectors | 4 |
| Peripheral Power Connectors | 2 × 4-Pin |
| Over Voltage Protection (OVP) | Yes |
| Under Voltage Protection (UVP) | Yes |
| Short Circuit Protection (SCP) | Yes |
| Over Power Protection (OPP) | Yes |
| Surge & Inrush Protection (SIP) | Yes |
| No Load Operation (NLO) | Supported |
| Power Good Signal | 100–150ms |
| Hold-Up Time | ≥16ms at 75% Load |
| Operating Temperature | 0–40°C |
| MTBF | 100,000 Hours |
| Regulatory Certifications | TÜV Rheinland, RCM |
| Energy Regulation | ErP 2014 |
| Environmental Compliance | WEEE, Triman |
| Product Dimensions | 150 × 140 × 86mm (W × L × H) |
| Warranty | 3 Year Warranty |
